Waterproof Gas Thermocouple RTD Platinum Rhodium Wire 0.3 , 0.4 , 0.5mm
Description:
For the measurement of higher temperatures we offer thermocouples with ceramic tubes, upon request with additional ceramic inner tubes.
The thermocouples (e.g. type S or type B) are insulated by a 2-hole or 4-hole insulating ceramic rod. The measuring point is laser-welded.
The thermocouple is protected against environmental influences.
We furnish all kinds of thermocouples with ceramic protective tubes at all lengths and designs.
Features:
1. Easy assembly and convenient for replacement;
2. Spring thermal element with good shock-proof performance;
3. Wide measuring range;
4. High mechanical strength, good pressure-resistant performance.
Application:
The Hot Runner Thermocouple has been designed to be used in below area,
1. Hot Runner bushings, drops and nozzles
2. Hot Runner manifolds
3. Plastics and rubber industry
4. Moulds used in injection molding machines
5. For direct installation in the process
Technical Parameters:
| Thermocouple & rtd | ||
| Ref No. | WR | Temp |
| Thermal element materials | B: PtRh30-Pt6 | 0~1600C |
| Ref No. | WZP | Temp |
PT100 | -200~+650C | |
| Pairs quantity of sensor wire | Simplex | |
| Ways of Mounting & Fixing | 1: without fixing device | |
| Types of connections box | 2: anti-spray (Protection class: IP65) | |
| Types of sensor end | G: variable section | |
| Diameter of protection tube | 0: ¢16 | |
| Measuring range | 0~1600 degree Celsius | |
| Shipping | By air, sea, express | |
| Sample time | 2~7 days | |
| Manufacture time | 7~30 days depending on order quantity | |
