Industrial MgO Mineral Insulated Cable / MI Cable With Stainless Steel 321 , 310 , 316 Sheath

Industrial MgO Mineral Insulated Cable MI Cable with stainless steel 321, 310, 316 sheath

Description:

1) The sheath cable are small outer diameter, quick heat responsive period, can be bent , long service life, fine air-tight, wide temperature measure range, high voltage resistant, anti-vibration, narrow mounting pipeline and can be used on bending condition

2) M.I. (Mineral Insulated) cable is used to insulate thermocouple wires from one another and from the metal sheath that surrounds them. MI Cable has two (or four when duplex) thermocouple wires running down the middle of the tube. The tube is then filled with magnesium oxide powder and compacted to ensure the wires are properly insulated and separated. MI cable helps to protect the thermocouple wire from corrosion and electrical interference

Specification:

1.Diameter : 3.0mm (CUSTOMIZED)

2.Model :K, E , T , J.

3.Type:Simplex

4.Material:SS310,INCONEL600,321,316L

5.Class of accuracy: I, II

6.Purity of MgO: ≥99.5%

Mineral Insulated Thermocouple Cable:

1. metal sheathed inert magnesium-oxide insulated thermocouple cable.

2. used to fabricate thermocouple probes and high temperature thermocouple extension wire.

3. can be welded, brazed, bent, coiled or formed.

4. Durable and withstands vibration under high temperatures and pressures.
