Aluminum Thermocouple Connection Head Good Mechanic Strength For Industry
KSE type Thermocouple Head
1.specification
Protection Tube Entry:
PF1/2", PF3/4", NPT1/2", NPT3/4", BSP1/2", BSP3/4", M20X1.5
Extension Wire Entry:
PF1/2", PF3/4", NPT1/2", NPT3/4", BSP1/2", BSP3/4", M20X1.5
| Item | Type | Features for Thermocouple Head |
| 1 | Cast Iron | * Rugged construction * Screw cover with inside thread * Moisture and dust resistant * Ideal for outdoor use |
| 2 | Burnished Die Cast Aluminum | * Small and Lightweight * Good corrosion resistance * Gasketed, weather resistant * Burnished finish * Safety chain on cover |
| 3 | Cast Aluminum Body and Cap | * Explosion resistant head * Rated for: Class III Class I, Group C, D Class II, Groups E, F, G * Screw cover * Moisture and dust resistant * Safety Ideal for outdoor use * Safety Utilizes barrier strip connector (optional) |
| 4 | Feraloy with Iron Alloy | * Explosion resistant head for 2-wire transmitter * Rated for Class I, Div 1&2, Groups C, D Class III Class II, Div 1 Groups E, F, G, Class III * Moisture and dust resistant * Ideal for outdoor use * Utilizes barrier strip connector (optional) |
sheathing, RTDs can operate in a temperature range of (-200 to 450) °C [-392 to 842] °F.
2.Main Features
1.Material and diameter of sheath will affect temperature range of the thermocouple, i.e. range of thermocouple will be increased with diameter for same sheath material; however, under condition of same diameter, range of therocouple will be determined by material of the sheath;
2.Fast response: smaller the product diameter is, faster the temperature will be changed;
3.Various installation options will meet requirements of different installation conditions;
4.Product with good mechanic strength and air tightness, could be applied under harsh conditions including vibration, low and high operating temperature;
