1"-4" Sanitary Ball Valve Stainless steel Pneumatic Clamp with Positioner
1"-4" Sanitary Ball Valve Stainless steel Pneumatic Clamp with Positioner
Quickly Detail:
Size:1/2"-4", DN10-DN100
Structure: Ball
Materials: Stainless steel, AISI 304/1.4301, AISI16L/1.4404
Standard: DIN, SMS, 3A, ISO,RJT....
Connection: Welding, Clamp, Thread, Flange
Flow pattern: Directly
Seat material: PTFE
Operating Type: Manual, Pnumatic, Control Head, Postioner...
Website: www.cndonjoy.com
Specification
| Product Name: | Stainless steel Pnuematic direct ball valve with Clamped Connection |
| Valve Body Material: | SS304 or SS316L |
| Seal Material: | PTFE |
| Max. Working Pressure: | 10Bar |
| Max. Working Temperature: | 120 degree C |
| Availably size: | DN25-DN100 or 1" - 4" |
| Availably connection: | Weld,Clamp,Thread, Flange |
| Availably standard: | DIN,SMS,3A |
| Ball Type: | Directly |
| Operated: | Manual,Pneumatic,Electric,control Head |
| Certificate: | FDA,CE,3A,ISO |
Design and Feature
1. Free of Maintenances
2. compact and portable
3. small operating torque
4. gasket complies with PTFE FDA 177.2600
5. Hand lever can be installed on the side of the valve body, no matter of the flow direction
6. It can be installed with pneumatic and electrick acuators.
7. With Cleaning and drainage port
Application:
It is widely used in beverage, brewing, oil refinery, cosmetic, chemical industrial
1, How about the surface polishing ?
Answer: Ra ≤0.8um
2, Shipment way choose.
Answer:If small qty package will suggest ship by express or airline,large qty will be ship by sea(LCL/FCL)
3, How about the delivery time ?
Answer:With the standard products normally delivery time will be10-15days after receive your down payment or full payment.
4. What about the payments Term
Answer: By T/T or L/C at Sight
If you need more informations,Please do not hesitate to contact us.
