Stainless Steel CIP System 360° Rotary Tank spray cleaning Ball,Thread Cleaning Ball
Stainless Steel CIP System 360° Rotary Tank spray cleaning Ball,Thread Cleaning Ball
Operating Principle
1. Rotary injector is hygenic tank cleaner,with 360degree coverage in a given tank or process container, the rotary jet head is driven by flow liquid through impeller in the pressure and flow increase will increase the length of the jet and the impact to the tank or vessel surface
2. Rotary injector with unique self cleaning function, internal is completely cleaning.
Quick Detail
Cleaning Ball
Connection: Thread , Bolt Pin
Size: 1",11/4",1.5", 2" (DN25,DN32,DN40,DN50)
Materials : SS304, SS316L
Specification
|
|
Stainless Steel CIP System 360° Rotary Tank spray cleaning Ball,Thread Cleaning Ball |
|
Material: |
SUS304/316L;PTFE |
|
Flow: |
4-45m³/h |
|
Inlet Pressure: |
4-10 bar |
|
Suggest Pressure: |
6 bar |
|
Available size: |
1.5"-DN40 |
|
Connection way: |
thread BSP, clamp |
|
Max temperature: |
95°C |
|
Max environment temperature: |
140°C |
|
Application Scope: |
Widely used in food and dairy products , Pharmaceutical, Chemical treatment, Transport equipment, Beverage |
|
Typical application: |
process containers and reactor; tank; transport irrigation equipment; fermentation; yeast breeding |
|
Advantages: |
Self-cleaning; low liquid consumption; heath design |
|
Typical cleaning methods: |
fixed installation CIP system |
|
Packaging Details: |
Bubble pack for each. Outside packing is carton or plywood cases. Or as per the request of customers. |
|
Delivery details: |
Usually within 20 days after receiving T/T down payment. |
Typical Application
1.Fixedinstallaiton CIP System
2.Process Containers and reactor
3.Store tank
4.Transport tank equipment
5.Fermentation
6.Yeast Breeding
Operating Principle
1. Rotary injector is hygenic tank cleaner,with 360degree coverage in a given tank or process container, the rotary jet head is driven by flow liquid through impeller in the pressure and flow increase will increase the length of the jet and the impact to the tank or vessel surface
2. Rotary injector with unique self cleaning function, internal is completely cleaning.
Why choose us:
1. Leading manufacturer and Top supplier in stainless steel
2. Low Prices Direct From Factory Suppliers.
3. Fast Delivery Around The Globe.
4. Professional OEM/ODM and Personalized private customize.
5. High Quality With Global Standards.
We Have cooperation with most logistics company, Such as TNT, UPS, FEDEX, DHL.
Packing: Cartons, Wooden Case
Delivery time: About 7 days. If bigger quantity can check it again.
If you need more information,please do not hesitate to contact us.
