Pneumatic Sanitary Diaphragm Valve Stainless Steel 316 Forged Body Double Acting
Pneumatic sanitary diaphragm valve Stainless steel 316 forged body double acting
Tag
Sanitary Diaphragm Valve with Plastic pneumatic actuator
Multi-function pneumatic diaphragm valve
Double location cylinder pneumatic diaphragm valve
Specifications
|
Product Name: |
Pneumatic sanitary diaphragm valve Stainless steel 316 forged body double acting |
|
Valve Body Material: |
SS316L |
|
Seal Material: |
Single sillcone gasket |
|
MaxWorking Pressure: |
8 Bar |
|
Max.Working Temperature: |
150 degree C |
|
Availably size: |
1''-4'', DN20-DN100 |
|
Availably connection: |
Clamp/weld/thread/special connection |
|
Availably standard: |
3A/BPE/DIN/ISO/IDF |
|
|
Manual,Pneumatic |
|
Availably structure: |
Straight, tee, U-type, tank bottom |
|
|
Smart valve positioner / C-TOP control / position sensor |
|
Certificate: |
3A/54-02 (1580), PED/97/23/EC, FDA.177.2600 |
|
Application scope: |
Dairy,food, beverage, pharmacy, cosmetic, etc |
|
Valve body: |
Forging or casting |
|
Configuration: |
Flexible with various valve seat |
Various configuration of Diaphragm valve
1. Didaphragm valve with Pisitioner/Process Controller (IL-TOP)
2. Diaphragm valve with Control Unit (C-Top)
3. Valve position Regulator
4. Position Sensor Module
5. Plastic Handle
6. Stainless steel handle
7. Stianless steel acutor
8. Electric Diaphragm valve
Product drawings
Tag: Forged diaphragm valve, Sanitary valve, Donjoy diaphragm valve.
