CA45DD G1 1/2" Goyen Type Dresser Nut Pulse Jet Valve For Dust Collector
CA45DD G1 1/2" Goyen Type Dresser Nut Pulse Jet Valve For Dust Collector
CA45DD /CA45DD010-300 / CA45DD010-305 /CA45DD000-301 type pulse jet valves . It is compression fitting pipe version, there are fixed nut at both ends which make it easy to install and use the valve.
It is also right angle with the 90° angle between the inlet and outlet, & solenoid control, 2-way dust collector valve used for pulsing large volumes of air into filter bags for particulate removal.
Technical Data of DD Series Pulse Jet Valves:
|
Model No
|
CA20DD
|
CA25DD
|
CA45DD
|
|
Port Size
|
3/4''
|
1''
|
1 1/2''
|
|
Pipe Connection
|
Dresser Nut
|
||
|
Diaphragm Number
|
1
|
1
|
2
|
|
Working Pressure Range
|
0.35 to 0.85 MPa (5 to 125 PSI)
|
||
|
Diaphragm Material
|
NBR, VITON
|
||
|
Valve Body Material
|
Aluminum (Diecast)
|
||
Ordering Code of DD Series Pulse Jet Valve:
