SCG353A044 dust collector valves , Professional diaphragm pulse valve

Pulse jet valve short description:

1, all volatge available, 110v AC, 220v AC, 24v AC, 24v DC

2, made of high quality enamelled wire solenoid coil, imported magnetic stainless steel 430FR armature assemblies, high grade dia casting ADC alumininum

3, working pressure 0.3~0.8MPa

4, ambient temperature range: -5~55℃

Pulse Jet Valve Features:

1, The diaphragm pulse valves are especially designed for dust collector service applications, combing high flow, long life and extremely fast opening and closing to produce reliable and economical operation.

2, The high flow, angle type bodies, springless construction, in combination with the special diaphragm assemblies give the unique operating features required for dust collector service applications.

3, Integral compression fitting for fast, easy, secure installation

4, Built-in silencers reduce noise and prevent foreign particles from entering the valve

5, The integral operators are provided with epoxy moulded F-class coils. Various optional waterproof and explosionproof solenoids for use in potentially explosive atmospheres(gas & dust) according to Directive ATEX94/9/EC can be mounted on the same basic valve

6, The valves satisfy all relevant EC directives.

Pulse valve internal structure and main parts:

Diaphragm Pulse Valve Model Specifications:

Details of pulse valve and overall dimensions:

We also sell solenoid coil and armature assmebly and diaphragm as kits for pulse valve:

Welcome your any enquiry, pls send your question to email:

brandon.bao@brandopneumatic.com
