Durable Black Double Decker Tents 25 X 50m With Customized Printing For Event Show
China 25x50m Customized Printing Black Tent Structure for Shows Expos
Liri Double Decker Tent Series:
| Type | Span Width | Bay Distance | Eave Height | Ridge Height | First Floor Height | Main Profile |
| DDS | 10m/32.8' | 5m/16.4' | 6.75m | 8.5m | 3.21m | 300x120x5mm |
| DDS | 15m/49.2' | 5m/16.4' | 6.75m | 9.34m | 3.21m | 300x120x5mm |
| DDS | 20m/65.6' | 5m/16.4' | 6.75m | 10.17m | 3.21m | 300x120x5mm |
| DDS | 25m/82' | 5m/16.4' | 6.75m | 11m | 3.21m | 300x120x5mm |
| DDS | 30m/98.4' | 5m/16.4' | 6.75m | 11.75m | 3.21m | 300x120x5mm |
| DDS | 40m/131.2' | 5m/16.4' | 6.75m | 13.5m | 3.21m | 300x120x5mm |
| ADDS | 15m/49.2' | 5m/16.4' | 6.75m | 8.6m | 3.21m | 300x120x5mm |
| ADDS | 20m/65.6' | 5m/16.4' | 6.75m | 9.43m | 3.21m | 300x120x5mm |
| The length can be extended by 5m bay such as 15m,20m,30m,40m...Customized size or shape is available. | ||||||
Liri Tent Series
Tent Roof Type |
Span Width | Bay Distance | Eave Height |
| Regular | 3m~60m | 3m/5m | 2.6m/3m/3.3m/3.88m/4.2m/5m/5.2m |
| Dome | 3m~40m | 3m/5m | 2.6m/3m/3.23m/3.88m/3.92m |
| High Peak | 3m~10m | 3m/4m/5m/6m/8m/10m | 2.5m/2.6m |
| Curve | 15m~40m | 5m | 3.87m/3.89m |
| Polygon | 10m~60m | 5m | 4m |
| Double Decker | 10m~30m | 5m | 5m |
Accessories of Our Black Tent Structure
- Covers: colourful cover, transparent cover, inflatable roof cover
- Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
- Wooden Flooring System: VIP cassette flooring, simple cassette flooring
- Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
- Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
- Fixing Methods: ground anchors, weight plate, expandable bolts
- Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
- Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
Material
Frame struss: Hard pressed extruded aluminium 6061 /T6(15HW) which can last 15 to 25 years.
Fabric cover: High quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc. <o: P>
Connecter: Strong hot-DIP galvanized steel, zinc thickness over 80um
Features & Specification
Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
Wind load: Max. 100km/h (can be reinforced)
Snow load: 75kg/sqm (snow can't stay if use big degree roof design)
Easy to be assembled and dismantled, removable
No pole inside, 100% room is available
Sizes can be customized(like side/leg height)
