XXG-250GF 70-250KV X Ray Flaw Detector Maximum Penetration 60mm DR Flat High Frequency
Price:
USD36225-USD40950/SET
MOQ:
1 SET
Delivery Time:
20-30 working days after receipt of your payment
Brand:
HUATEC
Product Description
XXG-250GF 70-250KV Maximum penetration 60mm DR flat High frequency X-ray Flaw Detector
Main performance:
Continuous exposure under the conditions of 35℃ 300kv/3mA, 250kv/3mA;
Wide input voltage range to meet the power supply of various generators;
Lightweight, strong penetration, stable performance;
More suitable for use in harsh and humid environments;
The operation interface is intuitive and easy to operate;
Main technical parameters
project name |
XXG-250GF |
|
X-ray generator |
Weight |
25kg |
Dimensions |
Φ295×704 (Φ×L) |
|
Controller |
Weight |
11kg |
Dimensions |
410×228×300 (L×B×H) |
|
Focus size |
3.0×3.0 |
|
Radiation angle |
40°×40° |
|
Maximum penetration(Fe) |
60mm (A3) |
|
kV Adjustment range |
70～250 kV |
|
mA Adjustment range |
0.5～3 mA(Stepping 0.1mA) |
|
Maximum power |
900W |
|
Leakage radiation value |
maximum 5.0msv/h |
|
Operating temperature |
-20℃～+50℃ |
|
Storage temperature |
-25℃～+70℃ |
|
Voltage |
85～264 VAC |
|
Power frequency |
45～65 Hz |
|
