Aluzinc Coated Steel Outdoor Power Cabinet, for Installing 19" Equipment and Battery

Aluzinc Coated Steel Outdoor Power Cabinet

ET9090216-UP

Summary

Available in different configurations, ESTEL outdoor cabinets are designed to protect equipment from external threats in all climates. Outdoor power cabinet is used for installing base station equipment, rectifier system, and batteries, etc. Different cooling options can meet thermal management requirement of different climate area.

Our outdoor cabinet includes multiple wall structure options for protecting telecom equipment in the best possible way, such as single layer wall construction, double layer wall construction, with or without thermal insulation, designed for different demanding conditions.

The cabinet is mainly used in wireless communication base stations, including a new generation of 4G / 5G systems, communications / network integrated services, access / transmission switching station, emergency communications / transmission etc.

Features

● IP55 rating (Optional IP65 available upon request)

● Multiple cooling options: forced air, air conditioner, heat exchanger, peltier device

● Single wall with optional energy efficient insulation for protection of equipment from sudden or rapid thermal shock

● Anti-theft multi-point lock rod system on all doors as standard

● 19”/21”mounting posts as standard

● Surface Treatment: deoil, acid pickling, phosphating, electrostatic spraying, high temperature solidification

● Professional outdoor anti- corrosion powder coating, strong weather resistance

● Cable entry is via the base as standard with side and roof available upon request

Specifications

Pictures
