28U High Anti-corrosive Outdoor Telecom Cabinet Stainless Steel IP65 One Front Door

28U High Anticorrosive Stainless Steel Outdoor Telecom Cabinet With Air Conditioner Cooling IP65

IP Enclosures 19”cabinet are designed for heavy duty outdoor applications to house sensitive data network equipment,transsimision equipment etc in harsh environments. They are suitable for internal and external installations.

Protection: Complies with IP65

Rack Unit Size: 28RU

External Size: W×D×H 650×650×1600mm

Material:

- Enclosure Body: 1.5mm stainless steel 304 sheet + 20mm PEF heat insulation

- Enclosure Door: 1.5mm stainless steel 304 sheet + 20mm PEF heat insulation

- 19” Rack Rails: 1.5mm galvanized steel sheet

- Enclosure Seal: Polyurethane rubber

Body: The robust monoblock body is 1.5mm stainless steel sheet. Precision automated manufacturing equipment ensures accuracy and consistent high quality. Flat face sealing surfaces increase seal life. Cable entry is incorporated into the bottom face.

Door: The surface mounted door is 1.5mm stainless steel sheet. It incorporates concealed removable hinges with captive pins. Doors are also designed for a 110° opening.

Seal: A high quality full perimeter seal provides excellent sealing over a long life.

Lock: 3 point locking system with key-lock swing handle. A full range of locking solutions are available upon request.

Surface Treatment: UL approved epoxy polyester powder-coated with a textured finish. 80-120 micron average thickness.

- Colour: RAL7035

Other Parameter
