IP55 Outdoor Equipment Enclosure , Heat Exchanger Cooling 19 Inch Rack Cabinet 40U
40U IP55 Sunproof Rainproof Heat Exchanger Cooling Outdoor Telecom Cabinet 19 Inch Rack
1. Cabinet Application
1.1 Base station
1.2 Mobile & Radio, 3G 4G 5G, Tetra, Microwave
1.3 Telecommunication
1.4 Internet service providers
1.5 Environmental monitoring
1.6 CCTV and security systems
2. Cabinet Specifications
| External Size | W*D*H 900*900*2100mm. |
|
Structure |
Double wall with insulation |
|
Cabinet Layout |
One compartment for installing 19” equipment |
|
Material |
Galvanized steel, 1.5mm thick outer plate, 0.8mm thick inner plate |
|
Equipment Installation Method |
19” rack |
| Protection Level |
IP55 |
| Cabinet Inlets | From cabinet bottom |
| Illumination/lighting | DC48V LED lamp |
| Heat Insulation | PEF |
|
Grounding Protection |
Copper bar |
|
Color |
Grey (support custom made) |
|
Cooling System |
Heat Exchanger and Fan |
|
Coating |
Anti-corrosion outdoor powder coating |
|
Accessories Options |
PDU, Environment monitoring system |
|
Alarm sensors |
The door sensor, water sensor, smoke sensor, temperature and humidity sensor |
| Flame retardant | Comply with GB5169.7 test A |
| Door type | With 1 front door |
|
Cabinet Lock |
Anti-theft three point lock(support padlock) |
| Package | Wooden case with pallets |
| Certificates | CE |
3.Theft Proof Design
3.1 Three theft lock theft proof design
Damage resistance of the theft proof lock meets GA/T 73-1994 "Mechanical Anti-theft Lock"class B requirement,supporting padlock.
3.2 Connection and fastening
(1) Use anti-loose threaded connection as structure and bearer connection.Anchor bolt for fixing cabinet use hot dip galvanized bolts.
(2) Door hings use inner hinge mode.
4.PDU and Monitoring Unit
5. Cabinet Dimensions
