Weatherproof Dual Compartment Aluminum Outdoor Telecom Cabinet For Housing Electronics

1.Cabinet Features

• Weatherpoof Cabinets for housing the electronics,  batteries, rectifier and inverter units and etc.
• Designed with flexibility in mind, ensuring a scalable solution for future upgrades or expansion.
• Constructed from aluminum with a powder-coated finish for durability
• Combined with concealed security hinges and a 3 point locking mechanism to provide the ultimate protection.
• Easy placement on location.
• The internal of the cabinet has 2 compartment.The left bay is for housing electronics equipment,the right bay is for batteries, rectifier and inverter units and etc.
• The cabinets provide a dust and water ingress rating of IP55 or better.
• The cabinets support Environment Monitoring Unit: temperature and humidity sensor, smoke sensor, water sensor and door-open alarm.
• The cooling system includes 2 air conditioners installed on the front doors.
• The layout of the cabinet is reasonably planned in order to facilitate cable access, fixing and grounding.
• The cabinet has entrance holes individually for power cable, signal cable and optical cable.
•  All the cables used in the cabinet is made from flame retardant materials.

2. Cabinet Description

• Double Bay Outdoor Enclosure is available in a variety of configurations, and they can be used in several different applications.
• Double Bay Outdoor Cabinet is an outstanding robust, cost effective, long service life solution for domestic and international projects. Custom widths, lengths and configurations are also available.
• Double Bay Outdoor Cabinet can support Equipments, Batteries, Environment Monitor Unit, PDU and etc. Ultimate security is provided by a three-point locking system. This series enclosures offer all the protection needed for outdoor requirements.

3. Cabinet Parameters

3.1  Material: Aluminum

3.2 Dustproof, Sunproof and Rainproof.

3.3 Standard 19” Rack Mountable Equipment.
3.4 Dimensions: W*D*H 1600*900*2000mm.

3.5 Electrical Grounding bar inside.

3.6 Doors: Lockable, With 2 front doors, and anti-theft 3-point lock with padlock optional.

3.7 Installation mode: installed on a concrete floor.

3.8 Heat Insulation: 20mm PEF heat insulation between inner wall and outer wall.

3.9 Cabling mode: routed in and out from the bottom.

3.10 Including -48VDC illumination lamp.

3.11 Accessories: PDU, Monitor, Light, Alarm Sensors (Based on request),Batteries.

3.12 Temperature Control: AC220V air conditioners

3.13 Protection level:IP55.

3.14 Certificates:CE.

4. Our Factory Instruction

Factory Size: 3000 Square Meters

No. of Main Production Lines: 5

Contract Manufacturing: OEM Service Offered, Design Service Offered, Buyer Label offered

Production Experience: 13 Years

5. Leading Time

Usually about 15-20 days. The exact lead time need to be confirmed according to the quantity of order.

6. Cabinet  Pictures
