Air Conditioner Cooling Outdoor Telecom Cabinet Galvanized Steel With Front / Rear Access
1000W Air Conditioner Cooling Outdoor Telecom Cabnet Galvanized Steel With Front & Rear Access
1. Cabinet Summary
The outdoor communication cabinet refers to a cabinet made of metal or non-metal material, directly under the influence of the weather, and does not allow unauthorized operators to access. Base station equipment, power supply, battery, temperature control equipment, transmission equipment and other ancillary equipment can be installed in the cabinet, which can provide reliable mechanical and environmental protection for the normal operation of internal equipments.
The cabinet is mainly used in wireless communication base stations, including a new generation of 4G / 5G systems, communications / network integrated services, access / transmission switching station, emergency communications / transmission etc.
2.Cabinet Features
2.1 Short construction period, less land occupation, broader application and lower construction cost
2.2 High integration, compact structure, easy installation and migration on later stage
2.3 High-performance cooling solution
2.4 Anti-theft three-point outdoor cabinet lock, excellent keyhole protection device
2.5 Professional outdoor anti-corrosion powder coating, strong weather resistance, waterproof & dustproof.
3. Cabinet Parameters
| Configuration | Item | Technical Parameter |
| Cabinet Body | Model | ET80120130-EQ |
| Size |
External Size W×D×H: 800mm×1200mm×1300mm Refer to the drawing. |
|
| Component | The whole cabinet includes three parts: the top cover, the cabinet body and the base. The installation method is floor mount. | |
| Material | Galvanized steel, single wall with heat insulation. | |
| Structure |
|
|
| Surface Treatment | Deoil, acid pickling, phosphating, electrostatic spraying, high temperature solidification | |
| Color | Anti-corrosion outdoor powder coating RAL7035 | |
| Ingress Protection | IP55 | |
| Working Temperature | -40°C～+85°C | |
| Cooling Method |
Air Conditioner
|
Cooling capacity: 1000W; Power Supply: DC48V; Installed on front door |
4. Cabinet Doors
5.Cabinet Cooling System
The cabinet has one 1000W cooling capacity installed on the fornt door
6.Cabinet Package
Wooden case with pallets.
