Integrated Wireless Outdoor Telecommunication Cabinet Base Station IP55 2 Bay Galvanized Steel Floor Mount

1. Cabinet Parameters

• External dimentions is W*D*H 1800*900*1800mm
• The color of the cabinet is gray color
• The material of the cabinet is galvanized steel,double wall with heat insulation
• Top cover shades cabinet from the sun
• 2 anti-theft front doors
• Anti-theft three point lock
• Individual cable entry holes from bottom of the cabinet
• Cooling system uses air conditioner
• The door sensor, water sensor, smoke sensor, temperature and humidity sensor optional
• Flame retardant comply with GB5169.7 test A
• The protection level is IP55
• CE certificates
• Floor mounting type
• Package:Wooden case with pallets

2. Cabinet instructions

This series two bays cabinet is a perfect choice for outdoor racking requirements.It offers a secure,climate controlled environment for any electronic equipment. Being made of sandwich structure steel,it’s strong enough to rack even the heaviest equipment.For those who need more than just standard enclosure, this series can also offer a truly the security of customized solution with lots of available options, providing a climate-controlled environment for any electronic equipment, electrical load panels and cable entry solutions.

3. Cabinet Application

Suitable used for outdoor application,such as:  Telecommunications,Base station,Trailer-based communications,Fiber Optics and Military and etc.

4. Cable Connections

• Use anti-loose threaded connection as structure and bearer connection.Anchor bolt for fixing cabinet use hot dip galvanized bolts.
• Door hings use inner hinge mode.

5. Air Conditioner Installation

1000W cooling capacity air conditioner is installed on the left front door.

6. Cabinet Internal Pictures

7. Cabinet Package And Shipment
