2 Bays 40U Waterproof IP55 Outdoor Control Cabinet

Price Negotiable

Price: 358-2143 usd

MOQ: 1 set

Delivery Time: 15-20 working days

Brand: ESTEL

Product Description

40U Waterproof IP55 Outdoor Control Cabinet Outdoor Electrical Cabinet

1. Cabinet Features

1.1 External Dimension is W×D×H 800×600×2000mm

1.2 Galvanized steel,single wall

1.3 Anti-theft three point lock

1.4 The cabinet includes 19” standard installation rack.

1.5 The cabinet cooling uses 4 fans.

1.6 Including -48VDC illumination lamp.

1.7 The layout of the cabinet is reasonable, which will facilitate cable access, fixing and grounding.

1.8 At the bottom of the cabinet, there are entrance holes individually for power cable, signal cable and optical cable.

1.9 The cabinet is dustproof, sunproof and rainproof, which is used in outdoor environment.

1.10 All the cables, sealing and heat insulation used in the cabinet are made from flame retardant materials, which comply with GB5169.7 test A

1.11 IP55 protection level.

2. Cabinet Parameters

Item	Type	Technical Parameter
Structure	Dimension	External Dimension W×D×H 800×600×2000mm
	Layout	One compartment
	Equipment Installation Method	19” standard rack,40U
	Door	One front door with three point lock for outdoor cabinet (support padlock)
	Material	Galvanized steel,single wall
	Structure	Assembled
	Ingress Protection	IP55
Temperature Control	Cooling	4 fans
Lighting	LED lamp	48V LED lamp
Temperature	Temperature	Working Temperature: -40°C ~ +55°C
		Storage Temperature: -50°C ~ + 70°C
		Transport Temperature: -50°C ~ +70°C
Humidity	Relative Humidity	5% ~ 100%
Pressure	Air Pressure	62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)
Radiation Intensity	Solar Radiation Intensity	1124 × (1±5%)W/m2
