KR90A Rotary Drilling Piling Rig Machine 90kn.M 1200mm
Price:
Negotiation
MOQ:
1 set
Delivery Time:
45 working days after received your payment
Brand:
Tysim
Product Description
| Technical Specification of KR90C Rotary Drilling Rig | ||
| Type | KR90A |
|
| Torque | 90 kN.m | |
| Max. drilling diameter | 1000/1200mm | |
| Max. drilling depth | 28m | |
| Speed of rotation | 6~30 rpm | |
| Max. crowd pressure | 90 kN | |
| Max. crowd pull | 120 kN | |
| Main winch line pull | 80 kN | |
| Main winch line speed | 75m/min | |
| Auxiliary winch line pull | 50 kN | |
| Auxiliary winch line speed | 40 m/min | |
| Stroke(crowd system) | 3500 mm | |
| Mast inclination(lateral) | ±3° | |
| Mast inclination(forward) | 4° | |
| Max. hydraulic pressure | 34.3 MPa | |
| Control hydraulic pressure | 3.9 MPa | |
| Travel speed | 2.8 km/h | |
| Traction force | 122 kN | |
| Operating height | 12705mm | |
| Operating width | 2690 mm | |
| Transport height | 3465 mm | |
| Transport width | 2690 mm | |
| Transport length | 11385 mm | |
| Overall weight | 24t | |
| Chassis | ||
| Type | Sinomach | |
| Engine | QSF3.8 | |
Our Services
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 countries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
FAQ
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
