GT1749V 701854 701854-5004S 028145702N Turbo Turbocharger For AUDI A4 A6 Seat Cordoba Leon Vw Caddy Polo ASV 1.9L TDI
GT1749V 701854 701854-5004S 028145702N Turbo Turbocharger AUDI A4 A6 Seat Cordoba Leon Vw Caddy Polo ASV 1.9L TDI
Specifiions:
| Part Number | 701854-5004S |
| Previous Version | 701854-0002, 701854-0003, 701854-0004, 701854-2, 701854-3, 701854-4 |
| OE number | 028145702NV225, 028145702V500, 028145702NV500, 028145702N, 028145702NX, 028145702NV |
| Year | 2000-04 |
| Description | Audi A4/A6 TDI, Volkswagen COMBI TDI, Caddy TDI, Commercial |
| CHRA | 703890-0150 (433395-0039, 703890-0130, 433395-0010, 433395-0019)(1102015920) |
| Turbo Model | GT1749V (S2) |
| Engine | ASV, TDI 110 |
| Engine Manufacturer | VW |
| Displacement | 1.9L, 1896 ccm ccm, 4 Cylinders |
| KW | 81/88/120 HP |
| RPM Max | 4250 |
| Fuel | Diesel |
| Angle a (compressor housing) | 323� |
| Angle � (turbine housing) | 230� |
| Bearing housing | 433145-0004 (433145-0005/722282-0002) (703880-0037/722282-0012/722282-0061) (1102017453) $89.00 NEW IN STOCK |
| Turbine Wheel | 434533-0002/434533-0037/434533-0039 (Ind. 43. mm, Exd. 35.9 mm, Trm 69, 9 Blades) (1102017441, 1102017438) NEW IN STOCK |
| Comp. Wheel | 434812-0001/434812-0002 (Ind. 49. mm, Exd. 32. mm, Trm 45, Extended back disc type 6 blades) (1102015400) NEW IN STOCK |
| Back plate | 700593-0006/703682-0023/703682-0045 (1102015306) (1102015300) NEW IN STOCK |
| Heat Shield | 433112-0001 (1102015342) NEW IN STOCK |
| Repair Kit | 732248-003/732245-0001 (1102015759) NEW IN STOCK |
| Actuator | 434855-0012 (1102017382) |
| Turbine Housing AR | VNT2 |
| Gasket (turbine inlet) | 210293 (Inox Steel) |
| Gasket (outlet) | 210311(Inox Steel) |
| Gasket (oil outlet) | 210243 (Paper) |
| Manufacturer | Honeywell-Garrett |
Appliions
2000-04 Volkswagen Commercial Caddy/Combi Tdi with TDI 110 Engine
2000-04 Volkswagen Passat with TDI 110 Engine
2000-04 Audi A4/A6 with TDI 110 Engine
2000- Seat Leon TDi SE with TDI 110 Engine
Pictures:
Contact:
Email/Skype:costelturbo@outlook.com
Shipping:
Depending on various circumstances, three different delivery methods have been taken:
1 By sea. 2 By air cargo. 3 By express service.
Delivery term
Our extensive stock of turbochargers allows us to offer 3-7 working day delivery service ensuring that you and your customer wait no longer than is necessary.
50-150 pcs--15-20 days, 150-300 pcs--25 days, over 300 pcs -- 30 days.
COSTEL Complete Turbo
A.our products have 12 months warranty.
B.Product are manufactured to OE standards of quality
C.All wheels are processed on the Schenck automatic balancing centre with air bearings to achieve lowest residual balance.
D.Cartridges are assemblied by automatic line, and are balanced with Turbo Technics VSR or Schenck .
E.All VNT turbochargers are tested on the G3 VNT Flow Bench.
F.All turbochargers are supplied with gasket kits.
PRODUCTS coverage
- Garrett(GT12,GTC14,GT15-25,GT37,GT42,GT45 etc),
- KKK (K03,K04,K06,K16,K27,K31,KP35,KP39,BV43,BV50,R2S etc),
- Schwitzer (S1B/S100,S2B/S200,S300,S400 etc),
- MHI (TD02,TF035,TD04,TD05,TD06 ,TD07,TD08 etc),
- Holset(HX30,HX35/HE341,HX40/HE431V,HX55/HE551,HT60,HX80 etc),
- IHI (RHF/RHB3,RHF/RHB4,RHF5/RHB5,RHG6,RHG7,RHG8 ,RHG9 etc),
- Toyota (CT9,CT10,CT12,CT16V,CT20,CT26 etc).
