Dot matrix Dynamic vandal proof keypad Metal , Outdoor Kiosk stainless steel keypad
Dot matrix Dynamic vandal proof keypad Metal , Outdoor Kiosk stainless steel keypad
Product Description
• Vandal proof stainless steel panel mount numeric keypad with 16 flat keys, metal dome connect PCB key switch technology. Ideal for applications in the public areas and harshest conditions.
Product Features:
• 16 flat keys design stainless steel keypad, by 4 x 4 Layout.
• Waterproof ,dust proof, vandal proof.shake-proof
• Laser engraved characters for excellent durable.
• Top metal panel with threaded bolt solution.
• Matrix output; also PS/2 or USB connector are available
• Customized layout is available
MAIN APPLICATION:
• These metal keyboard are made form Rugged Stainless Steel Material that is dust-proof, water-proof,vandal-proof, anti-rusty,anti-corrosive ideal for applications in the public areas and harshest conditions, such as Info-Kiosk, Internet Kiosk, Check-in Kiosk, Boarding Kiosk, Medical Kiosk, Industrial Control Platform, etc.
| Technical Specifications | ||
|
Material
|
All parts that are exposed to outside are built from 304 stainless steel that is dust-proof, water-proof,vandal-proof, anti-rusty,anti-corrosive |
|
|
ELECTRICAL DATA
|
Interface: | USB or PS2 |
| Supply Voltage | 5.0V DC±5% | |
| Current Rating: | appr. 30mA | |
| EMC Standard: | It is compliance with the council EMC directive 2004/108/EC | |
| EN55022: | 2006+A2:2010 | |
| EN55024: | 1998+A1:2001+A2:2003 | |
|
Environmental Characteristics
|
Operating temperature: | -20 C to + 60 C |
| Storage temperature: | - 40 C to + 80 C | |
| Operating RH: | 20-95% | |
| Atmospheric pressure: | 60-106Kpa. | |
| Mechanical Data | Key switch lifespan | more than 10 Mio actuations |
| Trackball lifespan | > 10 Mio revolutions | |
| Lifespan | > 5 years | |
| Reliability | MTBF | >5,0000H |
| MTTR | <30min | |
| Operation system | It is compatible to All windows, Linux, Unix, Mac OSX | |
