Customization 8 Keys Number vandal proof keypad Rear Panel Mount
Customization 8 Keys Number vandal proof keypad Rear Panel Mount
This metal numeric keypad Ideal for applications in the public areas and harshest conditions, such as
Info-Kiosk,Internet Kiosk, Check-in Kiosk, Boarding Kiosk, Medical Kiosk, Industrial Control Platform, etc.
Product Features:
1. 8 keys Stainless steel keypad with customization layout optional
2. Vandal resistant, water-proof with long life
3. Laser engraved characters for excellent durable.
4. Matrix output or other interface for consideration
5. OEM/ODM are available
6. Rear panel mounting solution
Technical Data:
|
Key Travel :
|
1.5mm
|
|
Switch Life :
|
>1 million of per key
|
|
Operation System :
|
WINDOWS98/ME/2000/2003/XP/Vista/Linux,Unix,MacOSX,iOS, Android
|
|
Supply Voltage :
|
5.0V DC±5%
|
|
Current Rating :
|
Appr. 30mA
|
|
EMC Standard :
|
Council EMC directive 2004/108/EC
|
|
EN55022 :
|
2006+A2:2010
|
|
EN55024 :
|
1998+A1:2001+A2:2003
|
|
Lifespan :
|
> 5 years
|
|
Operating temperature :
|
-20°C to +60°C
|
|
Storage temperature :
|
-30°C to +70°C
|
|
Operating RH :
|
20-95%
|
|
Atmospheric pressure :
|
60-106Kpa.
|
|
CompliantStandard
|
RoHS , CE and FCC
|
|
Protection Level :
|
IP65(front panel)
|
|
Vandal resistant :
|
IK10
|
|
Key Lifespan :
|
>1 million actuation
|
|
MTBF :
|
>50000H
|
|
MTTR :
|
<30min
|
Our Services:
Over the years, we have established a soft design and manufacture system to provide a products and solutions for customers based on their demands and different conditions.
”Good Products, Friendly Service” are our principle. OEM and ODM are available in our company. We do our best to make a suitable solution chain for our customers.
Why choose us?
1. Taking a prossional R&D team with over 10 years same idustrial experience members
2. Fast and suitable solution provied for customers
3. Short lead time: around 1-2 weeks production lead time from confirming design to develop to finish products
4. Strict QC system and inspection in each steps
5. High quality assurance(CE, ROHS, FCC,IP65/IP67 Certificates)
6. Customized item with MOQ in 1 set
7. OEM and ODM are available
