Brass Miniature Solenoid Valve Pilot Operated Normally Open NO 24VDC 12VDC
Price:
negotiation
MOQ:
5pcs
Delivery Time:
5 working days after received your payment
Brand:
Round Star
Product Description
brass miniature solenoid valve pilot operated normally open NO 24vdc 12v
The main features of the low-pressure solenoid valve is more beautiful, in the absence of stressful situations can also start, good sealing. Using authoritarian coil, when in use is not easily destroyed. Relative to other materials in terms of security is relatively high.
UD-series solenoid valve specification table
| model |
interface size
|
Orifice size (mm) |
Cv
|
working pressure (bar) | dimension | valvebody material | Weight(Kg) | |||
| NC | NO |
length×width×height (mm) |
||||||||
| AC220V | DC24V | AC220V | DC24V | |||||||
| UD-2 |
1/8＂ 1/4＂ |
1.5 | 0.1 | 0 ～ 30 | 0 ～ 20 | 0 ～ 8 | 0 ～ 8 | φ36×75 | SS304 | 0.4 |
| 2.0 | 0.2 | 0 ～ 20 | 0 ～ 15 | 0 ～ 8 | 0 ～ 8 | φ36×75 | 0.4 | |||
| UD-3 | 3/8＂ | 3.5 | 0.25 | 0 ～ 10 | 0 ～ 8 | 0 ～ 3 | 0 ～ 3 | φ45×81 | 0.5 | |
| UD-C-10N | 3/8＂ | 10 | 3.2 | 0.3～ 10 | 0.3～5 | 0.1～13 | 0.1～13 | 45×31×86 | copper,SS | 0.4 |
