20mm Two Way High Pressure Electric Valve , Diaphragm Solenoid Valve Stainless Steel
YSP series 2-way piston stainless steel high pressure solenoid valve DN 15 ～ 50 mm
high pressure solenoid valve Structural features
Pilot diaphragm, the maximum pressure 6.0M MPa Air Force, Navy ancillary products
Compact design and sophisticated appearance, low temperature rise, no noise, no leakage
Action in response to the rapid, reliable and high-frequency technology in Germany, export series, quality
The medium containing impurities, a filter must be installed before the valve (not less than 80 mesh strainer / cm 2); and no solidification or crystal phenomenon.
YSP-series solenoid valve specification table
| model |
Orifice size ( mm ) |
Interface size |
Cv
|
Working pressure (bar) | dimension |
weight Kg
|
|||
| NC | NO |
length×width×height A×B×C ( mm ) |
(Kg) | ||||||
| AC200V | DC24V | AC200V | DC24V | ||||||
| YSP-15J | 15 | 1/2＂ | 4.8 | 0.5～50 | 0.5～40 | 0.5～30 | 0.5～25 | 70×53×135 | 1.1 |
| YSP-20J | 20 | 3/4＂ | 7.6 | 0.5～50 | 0.5～40 | 0.5～30 | 0.5～25 | 74×57×142 | 1.3 |
| YSP-25J | 25 | 1＂ | 12 | 0.5～50 | 0.5～40 | 0.5～30 | 0.5～25 | 92×69×150 | 1.7 |
| YSP-32J | 32 | 11/4＂ | 20 | 0.5～50 | 0.5～40 | 0.5～30 | 0.5～25 | 110×85×164 | 2.7 |
| YSP-40J | 40 | 11/2＂ | 31 | 0.5～50 | 0.5～40 | 0.5～30 | 0.5～25 | 122×90×168 | 2.9 |
| YSP-50J | 50 | 2＂ | 48 | 0.5～50 | 0.5～40 | 0.5～30 | 0.5～25 | 160×117×190 | 4.7 |
YSP-series flange(NC) solenoid valve dimension table
| model | PN=1.6MPa GB/T9113.1-2000 flange connection dimension (mm) |
weight Kg |
||||||||
| DN | L | D | H | K | d | C | f | n-φ | ||
| YSP—32JF | 32 | 140 | 140 | 218 | 100 | 76 | 18 | 3 | 4-φ18 | 4.5 |
| YSP—40JF | 40 | 148 | 150 | 228 | 110 | 84 | 18 | 3 | 4-φ18 | 5.5 |
| YSP—50JF | 50 | 182 | 165 | 243 | 125 | 99 | 20 | 3 | 4-φ18 | 7.5 |
Founded in 1965, Yuyao No.4 Instrument Factory has been a professional manufacturer of solenoid valves and has enjoyed an excellent reputation through the past more than 50 years in China. With the introduction of foreign cutting-edge technology, and the sustained innovation and self-improving, the company has mastered the key technology and is keeping pioneer position in the field of fluid solenoid valve.
