Oil Surface Treatment Aluzinc Steel Coil For Corrugated Steel Sheet

DX51D + AZ 30 ~ 180g Hot Dipped Galvalume Steel (55% Al-Zn Coated Steel Coil)

Specification : EN10025-1995, DX51D + AZ

Coating Mass : AZ30 ~ AZ180

Surface Finish : Regular Spangle

Surface Treatment : Chromatic Treatment, Oiled or Resin Coated (Anti Finger Print)

Available Sizes

Thickness : 0.13 mm to 2.00 mm

Width : 600 mm to 1250 mm

Applications : Used in Duct, Microwave Ovens, Refrigerators, Washing Machine, Electric Range,

Air Conditioners, Automobiles, Muffler, Hose Clamps, Heat Shields, Buckets, Garden Tools , Pipe , Tool Shed , Chemical Plant etc.

Tips when Using Galvalume Steel Coil

1.Storage
Galvalume coil is supplied passivated or oiled to temporarily limit any risk of black rust formation. During transport and storage, all necessary precautions must be taken to keep the material dry and to prevent the formation of condensation. Improved protection can be obtained by the application of an Easyfilm coating.
2.Forming and joining
The forming and joining techniques currently used for uncoated steel sheets are also suitable for Aluzinc coil.
The coating thickness must therefore be compatible with both the desired degree of corrosion protection and the requirements of the forming and welding processes envisaged. Forming performance is improved if Aluzinc is coated with an Easyfilm thin organic coating.
3.Painting
Galvalume coil can be painted after degreasing and surface treatment when delivered oiled. Aluzinc coated with an Easyfilm thin organic coating can be painted directly, without any prior surface treatment. However, the paint must be compatible with the Easyfilm resin.
4.Weldability
In electrical resistance welding, the welding current must be suitably regulated and regularly adjusted. Electrode life can be extended by regularly stepping up the welding current and periodically dressing the electrodes.
