Flexible 3x3 video wall LG video wall 55 inch 1.8mm 230W ips panel Splicing image processing ISO9001 DDW-LW550DUN-THA3

Price Negotiable

Price: Negotiable

MOQ: 2pcs

Delivery Time: 3 working days upon payment

Brand: DDW

Product Description

Flexible 3x3 video wall LG video wall 55 inch 1.8mm 230W ips panel Splicing image processing ISO9001 DDW-LW550DUN-THA3

Parameters

Original SHARP commercial grade lcd video wall, 16:9 SHARP a-Si TFT-LCD;
700nits brightness, MEGA DCR contrast;
FHD physical resolution 1920x1080;
Only 1.8mm ultra narrow bezel , high quality , practical , good vision effect;
Signal interface rich, RS232, , DVI, VGA, YPbPr, AV;
HD video wall unit , high brightness , high contrast , high gamut;
Flexible structure design, easy installation, extensible, arbitrary combination;
Stable performance, suitable working for a long time;

Key features

Support a variety of signal ports
Built-in splicing module , support splice function
Support Creating one window PIP across the screen , roaming service , scaling , PIP
Support matrix joint control
Unique DNX motion supplement image processing technology
Dynamic image without motion trail
Splicing image processing RS-232 RJ45 loop-circuit input/output
Input by remote control with wire , mobile receiver head

Specifications

Model No.	DDW-LW550DUN-THA3
LCD Technology	LG a-Si TFT-LCD
Active Screen Diagonal	55"
Aspect Ratio	16:9
Total Bezel Width	1.8mm
Physical Resolution	1920x1080
Luminance(nits)	700cd/sqm
Contrast	4000:1
Viewing Angle	H 178°/V 178°
Pixel Pitch(WxH)	0.63×0.63mm
Active Display Area(WxH)	1209.6×680.4 mm
Panel Dimension(WxHxD)	1211.4x682.2x53.3mm
White Point	10,000 K
Display Colors	8Bit,16.7M
Refresh Rate	60Hz
Response Time	<=6ms
Life(hrs)	>60,000(hrs)
MTBF	> 100,000 h
Surface	Anti-glare
Standby Power Consumption	<3W
Maximum Power Consumption	≧ 250W
Power Supply	AC100~240V 50/60 HZ
Cooling	Low noise fans
Heat Dissipation	819 BTU/h (max)
Working Time Capacity	7x24x365hours
Application Area	Indoor/Semi Outdoor
Working Temperature	0°C~50°C
Working Humidity	0.85
Storage Temperature	-20-60°C \| -4-140°F
Storage Humidity	85% non-condensing
	1
VGA	1
CVBS IN	1
CVBS OUT	1
RS232 IN	1
RS232 OUT	1
ISP IN	1
IR IN	1
CODING BUTTON	1
AC IN	AC100-240V
Color System Support	PAL/NTSC/SECAM
Control Type	IR Remote &Software Control
Menu Language	English/Chinese(Multiple Language can be customized)
Vertical/Horizontal Display	Support
