55 inch LG lcd display control room video wall 12 V TFT Panel DDW-LW550DUN-TKB1
Price:
Negotiable
MOQ:
2pcs
Delivery Time:
3 working days upon payment
Brand:
DDW
Product Description
55 inch LG lcd display control room video wall 12V TFT Panel DDW-LW550DUN-TKB1
Key features
- Signal interface rich --- RS232, , DVI, VGA, YPbPr, AV;
- HD video wall unit--- High brightness, high contrast, high gamut;
- Flexible structure design ---easy installation, extensible, arbitrary combination;
- Stable performance, suitable working for a long time;
- Original LG commercial grade lcd video wall panel,16:9 a-Si TFT-LCD;
- 500nits brightness, 5000:1 contrast;
- HD physical resolution 3840 x 2160;
- Only 3.5mm Ultra narrow bezel, high quality, practical, good vision effect;
Service
Our customizable solutions offer a range of user-friendly features that streamline operation and enable the interconnectivity of your corporate control room, meeting rooms, and multi-screen display systems. Integrating a range of content types and signal formats, DDW’s multi screen video wall, control room display and digital signage systems can help you get your message across to customers more effectively.
Specifications
| 55" Videowall screen Specifications | ||||||||||
| Active Screen Diagonal | 65" | |||||||||
| Pixel Pitch(WxH) | 0.63x0.63 mm | |||||||||
| Active Display Area(WxH) | 1213.4x684.2x38.9mm | |||||||||
| Monitor Dimension(WxHxD) | 1209.6 × 680.4 mm | |||||||||
| Bezel Width | Total: 22mm | |||||||||
| Aspect Ratio | 16:9 | |||||||||
| Physical Resolution | 3840x2160(4K) | |||||||||
| Backight System | LED | |||||||||
| Luminance(nits) | 500cd/㎡ | |||||||||
| Contrast | 5000:1 (typ.) | |||||||||
| Viewing Angle | H 176°|V 176° | |||||||||
| Display Colors | 1.07G colors | |||||||||
| Refresh Rate | 60Hz | |||||||||
| Response Time | <=6.5ms | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| MTBF | > 100,000 h | |||||||||
| Surface | Anti-glare | |||||||||
| Standby Power Consumption | <5W | |||||||||
| Maximum Power Consumption | <400W | |||||||||
| Power Supply | AC100~240V 50/60 HZ | |||||||||
| Cooling | Low noise fans | |||||||||
| Heat Dissipation | 819 BTU/h (max) | |||||||||
| Working Time Capacity | 7x24x365hours | |||||||||
| Application Area | Indoor/Semi Outdoor | |||||||||
| Working Temperature | 0℃～50℃ | |||||||||
| Working Humidity | 0.85 | |||||||||
| Storage Temperature | -20-65°C | -4-140°F | |||||||||
| Storage Humidity | 85% non-condensing | |||||||||
| Daisy chain video wall controller Inputs, Outputs &Features | ||||||||||
| DVI-I DUAL LINK | 1 | |||||||||
| 1 | ||||||||||
| VGA | 1 | |||||||||
| CVBS IN | 1 | |||||||||
| CVBS OUT | 1 | |||||||||
| RS232 IN | 1 | |||||||||
| RS232 OUT | 1 | |||||||||
| ISP IN | 1 | |||||||||
| IR IN | 1 | |||||||||
| CODING BUTTON | 1 | |||||||||
| AC IN | AC100-240V | |||||||||
| Color System Support | PAL/NTSC/SECAM | |||||||||
| Control Type | IR Remote &Software Control | |||||||||
| Menu Language | English/Chinese(Multiple Language can be customized) | |||||||||
| Vertical/Horizontal Display | Support | |||||||||
| Combine Display | Support combine any horizental &vertical numbers of screens and show display | |||||||||
| Support combine all screens together to show one image | ||||||||||
| Solid Display | Support each screen input with separate signal | |||||||||
| PIP/Zoom/Roaming | Support open one window for each screen, each window can be zoomed &roaming internal freely | |||||||||
| Multiple Interfaces | Support DVI,,VGA,AV &multiple signal inputs | |||||||||
| Rich Resolution | Support 1080P,1080I,720P,480P &multiple resolution inputs | |||||||||
| Standard Packing | Full wood pallet | |||||||||
| Net Weight | 65kg | |||||||||
| Gross Weight | 80kg | |||||||||
| Quality Standard | ISO9001,CCC,RoHS,FCC | |||||||||
