8.4 Inch LCD Advertising Player Positive Screen Industrial Automation Monitor All Metal

     8.4 inch LCD monitor positive screen industrial automation monitor all metal factory direct sale

     Full industrial capacitive touch screen display is an application for industrial control, machinery and equipment, ship control systems, tower crane online monitoring, production assembly line management, medical equipment, video capture, LED screen control, multimedia player and car instruments, POS, etc. Designed a rugged economical touch screen display. It is mainly for the appearance of high demand, compact space and low cost affordable touch screen display users.

    Detailed introduction

     【Specifications】

· Product Type: BVS-084M1-6

· Product Name: 8.4 inch open display

· Installation: Open / embedded

· Shell color: black

【Product Parameters】

· Size: 8.4 inches

· Display ratio: 4: 3

· Resolution: 800 × 600

· Point spacing: 0.071 × 0.213mm

· Pixel pitch: 0.213 × 0.213mm

· Surface treatment t: matte

· Display area: 304.128 × 228.096mm

· Visual area: 307.2 × 231.1mm

· Brightness: 400cd / m2

· Contrast ratio: 800: 1 (Typ.)

· Display color: 16.2M

· Viewing angle e: 80/80/65/80 (CR≥10)

· Operating temperature: -0 ~ 70 ℃

· Menu languages: Chinese, English, French, Spanish, German,

· Storage temperature: -30 ~ 80 ℃

· Relative humidity: ≤80%

· Signal Interface: VGA

· Power Interface: DC5.5mm

· Support Interface: / BNC / USB /

· Touch: 10 point capacitance interface: USB

· Voltage: 12V Current: 3.3A

· 【Product acessories】

· Standard accessories: power supply, VGA cable

· Attached: Most products can provide customized services
