Single Mode 1310nm 1550nm Digital HD 1080p Video Converter With 1 Channel Reverse RS485
work with hikvision dahua cctv camera 1080P hdcvi TVI AHD to video fiber optical converter,with 1-channel reverse RS485
Description
It’s digital optical transmission system optimized for single-channel, which could compatible with the all-pattern video signal hold out 1-ch unilateralism signal at same orientation on an optical fiber. For obtained high quality transmission, the video signal adopted 8bit/10MHz digital sample technique full-digital transmitting channel. Power, optical video are easily inspected the indicators on the panels, so that the user could check the status visibly. The system series are high performance reliability transmission system for long distance of video
Feature
-
8bits digital video coding
All-digital uncompressed video transfer,stable reliable function
Wall-hung type and 19-inches/2U chassis card pack for choise
Adaptive data rate,without setting
Automatic compatible with PAL,NTSC and SECAM vide format
with a APC circuit,output optical power constant,widely dynamic range
status LED can indicate system work status
fiber transfer technology with WDM/CWDM/DWDM
Designed as industry-specific module,function expend easily
Special lightning portection design
No debugging after installing,easily for maintain
Support with customized and OEM machining
Ordering information
| Digital Video Optical Converter | ||||
| Technical Parameters | ||||
|
Fiber Interface |
Physical interface | FC/SC ST | ||
| Optical wavelength | single mode 1310,1550nm | |||
| Transmitting optical power | ≥-8dBm | |||
| Receiving sensitivity | ≤-30dBm | |||
| Transmitting distance | 10km/25km/40km/60km/80km optional | |||
|
Video interface
|
Video channel number | 8channels | ||
| Signal format | PAL/NTSC/SECAM | |||
| Video input / output resistance | BNC 75Ω unbalanced interface | |||
| Video input / output voltage | 1Vpp(typical),Max 1.5Vpp | |||
| Video bandwidth | 8MHz | |||
| Video sampling rate | 14MHz | |||
| Quantization range | 8bit | |||
| Differential increase | 30dBm | |||
| Differential phase | < 0.6 | |||
| Video SNR | 70dB (typical) | |||
| Color Brightness Delay Inequality | 10ns(typical) | |||
| Color Brightness Gain Inequality | ±10%(typical) | |||
| Expand options | ||||
|
Data
interface |
Physical interface | Industry standard terminal blocks | ||
| Working mode | Positive , negative, bi-directional data | |||
| Interface type | RS-232,RS-485/422,Manchester,Biphase | |||
| Communicating rate | 0~300Kbps | |||
| Data error rate | < 10-12 | |||
|
interface |
Input resistance | 30KΩ | ||
| Output resistance | 10KΩ | |||
| Nominal input / output level | 2Vpp | |||
| Audio bandwidth | 10Hz ~ 20kHz | |||
| Sampling rate | 14MHz | |||
| Quantization range | 16bit | |||
| weighted signal-to-noise ratio | ≥95dB | |||
| Total harmonic distortion | 0.1% | |||
| Physical interface | Industry standard terminal blocks | |||
| on-off interface | Physical interface | Industry standard terminal blocks | ||
| Input signal | Any active or passive alarm,on-off input,supporting TTL,RS-232/422/485 or passive switch,button | |||
| Output signal | Any active or passive alarm,on-off input,TTL,RS-232/422/485 or relay electrical shock input | |||
| Mode/ Parameters | Fiber Interface type | Transmitter Wave length (nm) |
Transmitter powerdBm |
Receiving sensitivity dBm | Saturation dB | Max Transmission Distanc e (Km) |
Optical Loss dBm/Km |
| multi-mode | FC | 850 | -18.5~-14 | -35 | -8 | 0~2 | 2 |
| ST | 1310 | -19.5~-16 | -36 | -9 | 0~2 | 2 | |
| FC | 1310 | -19.5~-16 | -36 | -9 | 0~2 | 2 | |
| single mode | FC | 1310 | -15~-10 | -34 | -8 | 0~20 | 0.5 |
| FC | 1310 | -12~-5 | -36 | -3 | 0~40 | 0.5 | |
| FC | 1550 | -5~0 | -38 | +2 | 0~60 |
0.25 |
Applications
