FLOWEXPERT DC Electric Diaphragm Pump KDP-32-34 High Pressure 100PSI for agriculture electric sprayer, pressure washer
FLOWEXPERTTM DC 12V 24V 100psi Miniature High Pressure Diaphragm Pump KDP-32-34 for Sprayer and Wash
APPLICATIONS
-
Water purification,filter machine,chemical metering and fluid supply.
-
High pressure pumps used in sprayers and spray fixtures for high plants.
-
Food,Beverage filling and liquid transfer.
-
Can be used for washing car and conditioner.
FEATURES
-
Long life, no leak
-
Built thermal protector
-
Self priming, fully automatic, easy installation
-
Special valve for liquid input and output
-
Numerous fittings options for greater mounting flexibility.
SPECIFICATIONS
-
Pump design: 2 chamber diaphragm
-
Max. flow: 1.34GPM(5.1L/min)
-
Port size: 3/8''(9.5mm)Hose Barb
-
Pressure max: 110psi
-
Diaphragm materials: Santoprene
-
Check valve made:EPDM or Viton
-
Voltage:12v or 24v dc
-
Liquid temp: 140 °F(60°C) Maximum
-
Body material: Cast Iron
-
Spring materials:Stainless Steel
THECHNICAL DATA
|
Model |
Volts(V) |
Flow Rate(LPM) |
Pressure Off(PSI) |
Amp Draw(A) |
|
KDP-3202 |
12 |
5.1 |
80 |
4.5 |
|
KDP-3402 |
24 |
5.1 |
80 |
2.8 |
|
KDP-3203 |
12 |
5.1 |
100 |
5 |
|
KDP-3403 |
24 |
5.1 |
100 |
3 |
| KDP-3208 | 12 | 6.3 | 135 | 8.3 |
| KDP-3408 | 24 | 6.3 | 135 | 4.5 |
| KDP-3210 | 12 | 6.3 | 150 | 10 |
| KDP-3410 | 24 | 6.3 | 150 | 5.5 |
CHEMICAL RESISTANCE
| Chemical Resistance Code | Max Temperature Resistance Code |
|
A —— Excellent B —— Good C —— Ordinary × —— Unacceptable － —— Unusable |
1 —— 20℃(68F) 2 —— 40℃(104F) 3 —— 60℃(140F) 4 —— 80℃(176F) 5 —— 100℃(212F) 6 —— 120℃(248F) |
| CHEMICAL | MATERIAL | |||||||
| PP | PTFE | FKM | NBR | EPDM | 95 Ceramic | |||
| Sulfuric Acid | 0-10% | A4 | A6 | A6 | B2 | A4 | A5 | |
| 10-75% | A3 | A6 | A4 | X | A3 | A5 | ||
| 75-100% | B2 | A4 | A4 | － | B2 | A5 | ||
| Nitric Acid | 10% | A3 | A5 | A5 | X | A2 | A5 | |
| 30% | A2 | A6 | A6 | X | A2 | A5 | ||
| 50% | B2 | A3 | A1 | X | X | A5 | ||
| Hydrochloric Acid | 0-25% | A4 | A6 | A3 | B1 | C3 | A5 | |
| 25-40% | A4 | A6 | A2 | X | C2 | A5 | ||
| Hydrofluoric Acid | 10% | B2 | A6 | A3 | X | A3 | － | |
| 30% | C2 | A6 | A4 | － | B3 | － | ||
| 60% | X | A6 | A4 | － | C2 | － | ||
| Acetic Acid | 20% | A2 | A6 | B1 | B2 | A2 | A5 | |
| 80% | B1 | A6 | X | － | － | A5 | ||
| Sodium Hydroxide | 20% | A3 | A6 | B1 | B2 | A3 | － | |
| 50% | A3 | A6 | X | B1 | A4 | － | ||
| Bromine Water | C1 | A3 | A2 | － | X | A1 | ||
| Ethyl Alcohol | A2 | A3 | A3 | X | B3 | A3 | ||
| Ketone | A2 | A6 | X | － | B2 | A3 | ||
| Freon 12 | X | A6 | A1 | X | B1 | A4 | ||
| Aluminum Chloride | A4 | A6 | A5 | B4 | A4 | A4 | ||
| Ammonia Liquid | A1 | A6 | C1 | B4 | B3 | A3 | ||
| Aqua Regia | C2 | A5 | B2 | － | C2 | A4 | ||
| Formaldehyde | A4 | A6 | A4 | X | A4 | A4 | ||
| Gasoline | X | A6 | B3 | B3 | X | A4 | ||
| Kerosene | A1 | A6 | A1 | B1 | X | A4 | ||
| Methyl Alcohol | A3 | A6 | B2 | B4 | A3 | A5 | ||
| Toluene | C1 | A4 | B1 | － | X | A5 | ||
| Trichloroethylene | C1 | A6 | A1 | － | X | A4 | ||
| Xylene | X | A6 | B1 | － | X | A5 | ||
| Nitric Acid Anhydrous | C1 | A3 | A1 | － | X | A5 | ||
| Oleum | X | A6 | A4 | － | X | A5 | ||
| Potassium Hydroxide | A4 | A6 | B1 | C2 | A5 | － | ||
USAGE SCOPE
Widely used in general industrial equipment, medical equipment, chemical equipment, agricultural (lawns and gardens), tourist vehicles, special vehicles, ships, beverage, vehicle cleaning, carpet cleaning, floor cleaning, water purification and water treatment equipment.
1. Production of agricultural use electric sprayer, pressure sprayer can also be hand modified electric sprayer (pressure sprayer in hand directly on the micro-pumps, adding a battery or hand lamp can be).
2. Solve vehicles, ships, yachts, boats, etc. in use diet, wash, shower, toilet, wash water.
3. Food and beverage processing and handling equipment, to achieve the transfer of liquid food, distribution, filling and so on.
4. Domestic water supply. For example, water-saving toilet, water-saving toilet, electric toilet, pressurized water system.
5. Solar energy industry.
6. Water purification industry. For example, purification equipment, water treatment equipment, drinking fountains, water machines. For towel disposal, drinking fountains, Coke machines, juice machines, dishwashers, disinfection machines, solar bonsai, car washing and other manufacturers supporting the glass.
7. Other liquid transfer needs, as well as measurement of spray equipment and systems. For example, garbage trucks, water truck, carpet cleaning equipment, floor cleaning equipment, cleaning equipment, vehicles, road construction equipment, medical equipment, chemical equipment, chemical equipment, disinfection equipment, cooling systems, pressurization systems.
