LTCC, MLCC, chip resistors and capacitors, filters, sensors, solar cells, RFID, thick film screen printer
Price:
Negotiable
MOQ:
1 Unit
Delivery Time:
15-30 days
Brand:
Hoting
Product Description
Application scope:
LTCC, MLCC, chip resistors and capacitors, filters, sensors, solar cells/monocrystalline silicon polysilicon, RFID (radio frequency identification system) circuits/antennas, etc., thick film circuit sensors (automotivemilitaryaerospacemedical applications), optical filters etc precision flat electronic components screen printing process.
Feature:
Fully automatic operation / unique design / superior performance / high precision
Parameter:
| MODEL | HP-2525HA | |
| Max.Printing Size | 250 X 250mm | |
| Printing Table Size | 320 X 320mm | |
| Max.Frame Size(outer) | 450 X 450mm | |
| Printing Product Thickness | 0 ~ 50mm | |
| Printing Table Flatness | ±10μm | |
| Printing Speed | 500 Sheet/H | |
| Repeat Printing Accuracy | ±5μm | |
| CCD Lens Adjustment Range | 350 X 350mm | |
| CCD Lens Adjustment Accuracy | ±10μm | |
| Electric Source | 220V 1PH | |
| Air Pressure | 0.6MPA | |
| Dimension (W × D × H) | 1510 X 1020 X 1530mm | |
| Weight | Approx.560kg | |
Optional: Auto loader and auto take off system.
