0.2W 0.5w 1w bridgelux warm white waterproof 3528 SMD chip led Diode for LCD TV backlight beads
0.2W 0.5w 1w bridgelux warm white waterproof 3528 SMD chip led Diode for LCD TV beads
- Features:
1. P-LCC-2 package.
2. White package.
3. Optical indicator.
4. Colorless clear window.
5. Ideal for backlight and light pipe application.
6. Inter reflector.
7. Wide viewing angle.
8. Suitable for automatic placement equipment.
9. Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
10. Available on tape and reel (8mm Tape).
11. The product itself will remain within RoHS compliant Version.
- Descriptions:
1. The 3528 series is available in soft red, orange, yellow, green, blue and white. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes the SMT TOP LED ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.
- Applications:
1. Automotive: Backlighting in dashboards and switches.
2. Telecommunication: Indicator and backlight in telephone and fax
3. Indicator and backlight for audio and video equipment.
4. Indicator and backlight in office and family equipment.
5. Flat backlight for LCD’s, switches and symbols.
6. Light pipe application.
7. General use
Package Dimension:
| Part No. | Chip Material | Lens Color | Source Color |
| DL-TOP3528W30-02W | InGaN | Yellow Diffused | warm White |
Absolute Maximum Ratings at Ta=25℃
| Parameters | Symbol | Max. | Unit |
| Power Dissipation | PD | 210 | mW |
|
Peak Forward Current (1/10 Duty Cycle, 0.1ms Pulse Width) |
IFP | 150 | mA |
| Continuous Forward Current | IF | 60 | mA |
| Reverse Voltage | VR | 5 | V |
| Electrostatic Discharge (HBM) | ESD | 1000 | V |
| Operating Temperature Range | Topr | -40℃ to +80℃ | |
| Storage Temperature Range | Tstg | -40℃ to +85℃ | |
| Soldering Temperature | Tsld | 260℃ for 5 Seconds | |
Electrical Optical Characteristics at Ta=25℃
| Parameters | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
| Luminous Flux * | Фv | 19 | 23 | 25 | lm | IF=60mA |
| Viewing Angle * | 2θ1/2 | --- | 120 | --- | Deg | IF=60mA |
| Chromaticity Coordinates | x | --- | 0.45 | --- | nm | IF=60mA |
| y | --- | 0.43 | --- | nm | IF=60mA | |
| Color Rendering Index | RA | 70 | 75 | --- | IF=60mA | |
| Forward Voltage | VF | 3.0 | 3.3 | 3.8 | V | IF=60mA |
| Reverse Current | IR | --- | --- | 10 | µA | VR=5V |
