0.80Mm Height 4014 3014 Top View White SMD LED 6000 -7500K 0.1W for panel light led tube


0.80Mm Height 3014 & 4014 Top View White SMD LED 6000 -7500K 0.1W for panel light led tube

1. Features:

• P-LCC-2 package.
• 3014 package.
• Optical indicator.
• Colorless clear window.
• Ideal for backlight and light pipe application.
• Inter reflector.
• Wide viewing angle.
• Suitable for automatic placement equipment.
• Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
• Available on tape and reel (8mm Tape).
• The product itself will remain within RoHS compliant Version.
• 3014 warm white/ natural white/ cool white led

1. Descriptions:

• The TOP 3014 & 4014 series is available in soft red, orange, yellow, green, blue and white. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes the SMT TOP LED ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.

1. Applications:

• Automotive: Backlighting in dashboards and switches.
• Telecommunication: Indicator and backlight in telephone and fax
• Indicator and backlight for audio and video equipment.
• Indicator and backlight in office and family equipment.
• Flat backlight for LCD’s, switches and symbols.
• Light pipe application.
• General use.


 Package Dimension of 3014 & 4014 smd led:





• Absolute Maximum Ratings at Ta=25℃


Electrical Optical Characteristics at Ta=25℃


Notes:

• Luminous Intensity Measurement allowance is ± 10%.
• θ1/2 is the off-axis angle at which the luminous intensity is half the axial luminous intensity.
• It use many parameters that correspond to the CIE 1931 2°. X, Y, and Z are CIE 1931 2° values of Red, Green and Blue content of the measurement.


Typical Electrical / Optical Characteristics Curves of 3014 & 4014 smd led
(25℃ Ambient Temperature Unless Otherwise Noted)

CIE Chromaticity Diagram:



Chromaticity Coordinates Specifications for Bin Rank:

(IF=20mA, Ta=25℃)

Notes:

1. Color coordinates measurement allowance is ± 0.01.
2. One delivery will include up to two consecutive color ranks and three luminous intensity ranks of the products the quantity-ratio of the ranks is decided by DUOBLE LIGHT


Reel Dimensions of 3014 & 4014 smd led :



Carrier Tape Dimensions of 4014 smd led:
Loaded quantity 3000 PCS Per reel.
