3528 Rgb SMD Led 1.90mm Height in black shell Top View Full Color Chip LEDs

• P-LCC-4 package.
• White package.
• Optical indicator.
• Colorless clear window.
• Ideal for backlight and light pipe application.
• Inter reflector.
• Low current (2mA) operation.
• Wide viewing angle.
• Suitable for automatic placement equipment.
• Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
• Available on tape and reel (8mm Tape).
• The product itself will remain within RoHS compliant Version.

• Descriptions:

• The 3528 is available in soft red, orange, yellow, green, blue and white. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector, this feature makes the SMT TOP LED ideal for light pipe Application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.

• Applications:

• Automotive: Backlight in dashboards and switches.
• Telecommunication: Indicator and backlight in telephone and fax.
• Indicator and backlight for audio and video equipment.
• Indicator and backlight in office and family equipment.
• Flat backlight for LCD’s, switches and symbols.
• Light pipe application.
• General use.

• Package Dimension:
• Absolute Maximum Ratings at Ta=25℃

• Parameters	Symbol		Max.	Unit
  Power Dissipation	PD	Hyper Red	72	mW
  		Pure Green	100
  		Blue	100
  Peak Forward Current (1/10 Duty Cycle, 0.1ms Pulse Width)	IFP	Hyper Red	100	mA
  		Pure Green	100
  		Blue	100
  Continuous Forward Current	IF	Hyper Red	30	mA
  		Pure Green	25
  		Blue	25
  Reverse Voltage	VR		5	V
  Electrostatic Discharge (HBM)	ESD		400	V
  Operating Temperature Range	Topr		-40℃ to +85℃
  Storage Temperature Range	Tstg		-40℃ to +100℃
  Soldering Temperature	Tsld		260℃ for 5 Seconds

Electrical Optical Characteristics at Ta=25℃

• Parameters	Symbol	Emitting Color	Min.	Typ.	Max.	Unit	Test Condition
  Luminous Intensity	IV	Hyper Red	490	670	---	mcd	IF=20mA (Note 1)
  		Pure Green	1050	1150	---
  		Blue	380	550	---
  Viewing Angle	2θ1/2	Hyper Red	---	120	---	Deg	IF=20mA (Note 2)
  		Pure Green	---	120	---
  		Blue	---	120	---
  Peak Emission Wavelength	λp	Hyper Red	---	640	---	nm	IF=20mA (Measurement @Peak)
  		Pure Green	---	518	---
  		Blue	---	468	---
  Dominant Wavelength	λd	Hyper Red	---	630	---	nm	IF=20mA (Note 3)
  		Pure Green	---	525	---
  		Blue	---	470	---
  Spectral Line Half-Width	△λ	Hyper Red	---	20	---	nm	IF=20mA
  		Pure Green	---	35	---
  		Blue	---	25	---
  Forward Voltage	VF	Hyper Red	1.80	2.00	2.40	V	IF=20mA
  		Pure Green	3.00	3.30	4.00
  		Blue	3.00	3.30	4.00
  Reverse Current	IR	Hyper Red	---	---	10	µA	VR=5V
  		Pure Green			50
  		Blue			50
