12-16V 850nm Infrared Emitting Diode 10W High Power COB IR Led 20*20mm Fully Dimmable
Price:
Negotiated
MOQ:
100PCS
Delivery Time:
5-7 working days after received your payment
Brand:
DOUBLE LIGHT
Product Description
10W high power COB IR led with 12-16V 850nm Infrared emitting diode
- Features
- Long operating life
- Highest flux
- More energy efficient than incandescent and most halogen lamps
- Low voltage DC operated
- Instant light (less than 100ns)
- Fully dimmable
- No UV
- Superior ESD protection
- RoHS compliant
- Applications
- Commercial lighting
- Advertisement
- Architectural lighting
- Street lamps
- Package Dimension:
- Opto-Electronical Specification
| Parameters | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
| Radiant Intensity (Note 1) * | Ee | 860 | 1600 | --- | mW/sr | IF=350mA |
| Viewing Angle (Note 2) * | 2θ1/2 | --- | 120 | --- | Deg | IF=350mA |
| Peak Emission Wavelength | λp | --- | 850 | --- | nm | IF=350mA |
| Spectral Bandwidth | △λ | --- | 50 | --- | nm | IF=350mA |
| Forward Voltage | VF | 12.6 | --- | 16.2 | V | IF=350mA |
| Reverse Current | IR | --- | --- | 10 | µA | VR=45V |
Buy Led components, choose long history manufacturer---DOUBLE LIGHT
our various shipping to meet all kinds of customers requirement
our cetifications to guarantee each items's quality
choose DOUBLE LIGHT, your expert LED components nearby!
