4KW DIESEL AIR PARKING HEATER KEEP MOTOR HOMES WARMER FUEL SPACE VAN
4KW Diesel Air Parking Heater Keep Motor Homes Warmer Fuel Space Van
Two Years Warranty
Air Parking Heater Product Advantages
1. Lower fuel consumption, instant heating.
2. Compact structure is convenient to install.
3. No noise operation to ensure comfortable driving.
4. Continuous functional monitoring to reduce diagnosing time.
Air Parking Heater Working Principle
Combustion supporting air from surrounding environment mixes with diesel from fuel tank. Then, the mixture is ignited in combustion chamber. Thermal energy will heat the fresh air and circle air and send it back to compartment.
Air Parking Heater Package List
| 1 | Parking heater |
DC12V(24V) |
1 |
| 2 | Main wiring Bundle |
DC12V(24V) |
1 |
| 3 | Oil pump |
DC12V(24V) |
1 |
| 4 | Filter | 1 | |
| 5 | Oil pipe(from pump to heater) | Φ4/ Φ2 L=6800 | 1 |
| 6 |
Oil pipe(from pump to tank) 90 |
Φ5/ Φ2 L=1200 | 1 |
| 7 | Control timer |
DC12V(24V) |
1 |
| 8 | Protective gasket(control) | 1 | |
| 9 | Inlet air pipe | Φ29/ Φ25 L=600 | 1 |
| 10 | Exhaust pipe | Φ24 L=700/1000 | 1 |
| 11 | Gasket | 81*110*6 | 1 |
| 12 | Reducing tee | 10-6-10 | 1 |
| 13 | Reducing tee | 12-6-12 | 1 |
| 14 | Oil pump clip | D=32 | 1 |
| 15 | Inlet air pipe clip | Φ16/ Φ25 | 1 |
| 16 | Exhaust pipe clip | Φ24/ Φ28 | 1 |
| 17 | Inlet air pipe fixing clip | Φ24 | 2 |
| 18 | Exhaust pipe fixing clip | Φ27 | 2 |
| 19 | Oil pipe joint | Φ4.1/ Φ10.5 L=50 | 4 |
| 20 | Oil pipe joint | Φ3.5/ Φ9.5 L=50 | 2 |
| 21 | Oil pipe clip | Φ8/ Φ10(9) | 4 |
| 22 | Oil pipe clip | Φ9/ Φ11(10) | 8 |
| 23 | Oil pipe clip | Φ12/ Φ14 | 2 |
| 24 | Gasket | Φ6/18 | 4 |
| 25 | Nut | M6 | 4 |
| 26 | Self drilling tapping screw | ST5.5*25 | 4 |
| 27 | Self drilling tapping screw | ST5.5*30 | 1 |
| 28 | Self tapping screw | ST4*16 | 1 |
| 29 | Self tapping screw | ST3*20 | 1 |
| 30 | Cable ties | 200mm | 10 |
| 31 | Oil suction pipe | Φ5*600 | 1 |
| 32 | Clip | 2 | |
| 33 | Grill | 1 |
Our Services
1. We are manufacturer (not dealer)
All products from JP China Trade Int'l Co., Ltd are made by ourselves, with lower price, good quality and assured full after service.
2. Service
1. We can manufacture products according to your special demand and provide you with solution aimed to different type of vehicles.
2. We always keep certain inventory level of spare parts, which means the replacement can be shipped to you right away.
Exhibition photos
