• Homag 4-086-05-0351 (4086050351) BECKHOFF KL9100 Power Supply Module 24 DV Bus Terminal

  The KL9100 power feed terminal makes it possible to set up various potential groups with the standard voltage of 24 V DC. It is widely used with Homag machines. Homag part number 4-086-05-0351 (4086050351)


  KL9100 potential supply terminal technical data:

  Technical data	KL9100
  Nominal voltage	24 V DC
  Current load	≤ 10 A
  Power LED	green
  PE contact	yes
  Renewed infeed	yes
  Connection facility to additional power contact	1
  K-bus, looped through	yes
  Bit width in the process image	0
  Electrical isolation	yes
  Housing width	12 mm
  Weight	approx. 50 g
  Side by side mounting on Bus Terminals with power contact	yes
  Side by side mounting on Bus Terminals without power contact	yes
  Operating/storage temperature	-25…+60 °C/-40…+85 °C
  Pluggable wiring	for all KSxxxx Bus Terminals
  Approvals/markings	CE, UL, ATEX, DNV GL
  Ex marking	II 3 G Ex nA IIC T4 Gc



  There are also many other EtherCAT terminals products made from Beckhoff, please send the model number and images, we will check and reply you quickly.
