36 Connector Fiber Optic Polishing Equipment Fixture Jigs
FC/UPC Fiber Optic Connector Polishing Jigs 36 Ports 3D Pass For Four Corners Polishing Machine
Description:
- The polishing jigs (or also be called polishing fixture) is using to fix the fiber optic connector when polishing.
- It is one of most importance part in the fiber optic patch cord production line.
- A good polishing jigs can help make to high quality that can pass 3D of fiber optic patch cord / pigtail.
- This polishing jigs is designed for corner pressure fiber optic polishing machine only.
- It has 36 FC/APC adapter on the jigs, maximum can polish 36 connectors each time, increase grinding efficiency
- It is suitable for FC/APC connector polishing style.
- Come with 36 positions for connector head.
- Polishing 36 connector a time.
- FC/APC poloshing jig is available in 24 ports, 32 ports, and maximum 36 ports.
Feature:
- The interference rate of 2. is over 90%.
- High quality steel construction, high precision.
- Each grinding disc can be fitted with a plurality of grinding heads, and the production efficiency is high.
- Adapters interchangeable to extend the service life of the grinding disk.
- Three kinds of grinding heads, SC/PC, FC/PC, ST/PC, interchangeable.
- The utility model saves the number of the grinding disk and saves the production cost.
- Grinding can be integrated grinding disk, also suitable for rework.
- The use of independent afterburner way to eliminate the grinding head of different length of exposure on the impact of grinding.
- According to customer requirements design, APC, MPO, E2000, MTP, MPX and so on.
Specification
Applications:
| Product Type | Application |
| D |
· Lapping for Fiber optic connector, fiber array, glass pig tail(angel removal, rough grinding, medium polishing, fine finishing) ·Polishing for magnetic heads and hard disks ·Lapping and polishing for optical glasses, optical crystal , LED ·Lapping and polishing for Semiconductor wafer (gallium arsenide, indium phosphide etc.) ·Edge polishing for silicon wafer |
| SC |
·Epoxy and glass removal ·Lapping and polishing for plastic ferrules ·Fine finishing and polishing for magnetic heads |
| AO |
·Polishing for fiber optical connectors ·Polishing for silicon wafer used in Solar cells ·Polishing for hard disks ·Polishing for ITO ·Lapping and polishing for optical crystal |
| CO |
·The final polishing for fiber optical connectors ·Polishing for optical devices |
| SO | ·The final super-precise polishing of optical fiber connector |
Specifications:
| Type | D(Diamond) | SC (Silicon Carbide) | AO(Aluminum Oxide) | CO(Cerium Oxide) | SO(Silicon Oxide) | ||
| Grit Size/um | 30 | Green | Light Green | Green | |||
| 20 | White | ||||||
| 16 | White | ||||||
| 15 | Yellow-Green | Tawny | Light Green | Brown | |||
| 12 | Yellow | ||||||
| 9 | Blue | Orange | Gray-green | Blue | |||
| 6 | Yellow | ||||||
| 5 | Gray-green | White | |||||
| 3 | Pink | Tan | Pink & White | ||||
| 2 | Gray-green | Bright Green | |||||
| 1 | off-white | Lavender | Gray-green | Blue | |||
| 0.5 | off-white | Brown-yellow | White | White | |||
| 0.3 | White | Dark Red | |||||
| 0.2 | Grey | ||||||
| 0.1 | Light Brown | White | |||||
| 0.02 | Transparent | ||||||
| 0.01 | Transparent | ||||||
| Recommended Polishing Medium | Water/Oil | Water/Oil | Water/Oil | SOQ-12D | Water | ||
| Standard Size |
Disk:Φ70mm, Φ110mm, Φ127mm(5inch), Φ203mm(8inch) |
||||||
|
Sheet: 114mm*114mm, 152mm*152mm(6inch), 228*228mm(9inch) |
|||||||
| Note: Other film sizes are available upon request. | |||||||
