Brown Excavator Engine Parts Truck Clutch Disc Replacement Assy MAZ Model 236HE 182 - 1601130
182 - 1601130 Driven Disk Assy For Engine Parts MAZ Model 236HE
Quick Detail:
Item Type: Driven Disk Assy
Engine Model: MAZ 236HE
Part Number: 182 - 1601130
Appliion:Truck
Engine Type: Diesel
Condition: New
Sample:Available
Specifiions:
Pressure Disk With Casing Assy For MAZ 236HE Engine Parts OEM 182 - 1601090
| Product name | Driven Disk Assy |
| Model | MAZ 236HE |
| Part No | 182 - 1601130 |
| Suitable for | Truck |
| Sample order | Available |
| Net weight | 36kg |
| Package | Neutral package or special package to meet your requirements |
| Payment | T/T, L/C, Westernunion, |
Description:
Driven Disk Assy of 236HE engines for MAZ trucks
| 313020-Ï2 | Rivet |
| 184.1601158 | Thrust pin |
| 184.1601153 | Damper disk |
| 184.1601167 | Disk spring |
| 161.1601142 | Driven disk hub |
| 181.1601150 | Damper spring |
| 184.1601131 | Driven disk with friction lining, assy |
| 184.1601138* | Friction lining |
| 184.1601132 | Driven disk with plates, assy |
| 184.1601134 | Driven disk with damper rings |
| 184.1601135 | Spring plate |
Parameter of MAZ Engine Model 236HE
| Number of cylinders | 6 |
| Cylinder bore, mm | 130 |
| Piston stroke, mm | 140 |
| Engine displacement, L | 11,15 |
| Compressor ratio | 16,5 |
| Rated power, kW (hp) | 220,6 (300) |
| Maximum torque, N.m (kgf.m) | 1274 (130) |
| Crankshaft speed at maximum -1 torque, min , max | 1100-1300 |
| Fuel-air mixing method | Direct injection |
| Fuel feed equipment | Separate type |
| High-pressure fuel injection pump | Six-plunger (in-line or V-type) |
| Injectors | Closed, with multi-jet sprayers |
| Lubriion system | Composed type: pressure-forced and splashing, with oil cooling in oil-liquid heat-exchanger. Besides, oil delivers through the system of channels and pipelines for jet cooling pistons |
Packaging & Delivery
Delivery time: 1-3days(if goods in stock only 1 day,if out of stock more than 7days)
Packaging Detail:Standard or as per your requirement
Port:Huangpu,Guangzhou
More about our service:
1. Packing:Standard or as per customer requirement
2. Market:popular in Southeast Asia,Mid-East,South America,Africa and so on.
3. Delivery time:For stock parts 2-3days,for out of stock parts 15-30days
4. Shipment:Vessel,Air freight or Express(DHL,TNT,FedEx,UPS,EMS)
5. Your logo and design are welcome
6. Able to manufacture according to customer’s quality
7. Best control of product quality
8. Fast delivery,excellent after-sale service
9. Over 10 years experience.
