Cylinder Block 2042059 Excavator Hydraulic Parts Valve Plate 2044792 & 2044793
Hydraulic Main Pump HPK055 Cylinder Block 2042059 and Valve Plate 2044792 & 2044793
this cylinder block and valve plate will be provided and sold together.
it is used as the spare parts for hydraulic main pump HPK055 to repair it.
the weight for HPK055 cylinder block and valve plate together is about 2.6KG/PC.
and when it used to Hitachi excavator model ZX120-6,
the part numbder for the cylinder block is 2042059,
the part numbder for the valve plate is 2044792 and 2044793.
they are different between the front side and rear side,
so when you decide to order one side only,
please point out that you need the front side or rear side.
HPK055 Main Pump includes below parts:
| Model | DESCRIPTION | QUANTITY |
| HPK 055 (ZX120-6 Hydraulic Main Pump) |
CYLINDER BLOCK & VALVE PLATE FRONT | 1 |
| CYLINDER BLOCK & VALVE PLATE REAR | 1 | |
| DISC SPRING SET | 4 | |
| SET PLATE & BALL GUIDE | 1 | |
| PISTON SHOE SET | 9 | |
| SHOE PLATE | 1 | |
| SWASH PLATE FRONT & CRADLE | 1 | |
| SWASH PLATE REAR & CRADLE | 1 | |
| SERVO PISTON | 1 | |
| SPRING COMPRES | 1 |
Related Parts are as floowing:
|
Part No |
Parts name |
|
1026892 |
CASING;FRONT |
|
2038178 |
SHAFT;DRIVE |
|
4355286 |
RACE;INNER |
|
4229543 |
RING;RETAINING |
|
4280841 |
BRG.;ROL. |
|
991342 |
RING;RETAINING |
|
4343074 |
O-RING |
|
4198956 |
PIN |
|
2042069 |
PLATE |
|
M340613 |
BOLT;SOCKET |
|
1025666 |
PLATE;SWASH |
|
4382272 |
PLATE |
|
4407464 |
PLATE |
|
9134109 |
PLUG |
|
4506408 |
O-RING |
|
2042059 |
ROTOR |
|
4289874 |
SPRING;DISC |
|
3065991 |
BUSHING |
|
3065989 |
RETAINER |
|
8071391 |
PISTON |
|
4410166 |
O-RING |
|
1025540 |
CASING;REAR |
|
2038174 |
SHAFT;DRIVE |
|
1025667 |
PLATE;SWASH |
|
4355279 |
BRG.;ROL. |
|
927488 |
RING;RETAINING |
|
3076 |
CASING;PUMP |
|
4355272 |
BRG.;NEEDLE |
|
4355277 |
BRG.;NEEDLE |
|
4461927 |
BRG.;NEEDLE |
|
4271350 |
PIN;KNOCK |
|
4422627 |
PIN;KNOCK |
|
2044792 |
PLATE;VALVE |
|
2044793 |
PLATE;VALVE |
|
4428917 |
PISTON;SERVO |
|
4397537 |
SPRING;COMPRES. |
|
4409640 |
PIN;KNOCK |
|
4432356 |
PIN |
|
4436322 |
RING;BACK-UP |
|
4180349 |
O-RING |
|
4200227 |
PIN |
|
3081504 |
LINK |
|
4397509 |
PIN |
|
4465289 |
PIN |
|
4404102 |
PIN |
|
4144013 |
PIN;SPRING |
|
4116299 |
PIN;SPRING |
|
M341240 |
BOLT;SOCKET |
|
495841 |
WASHER;SPRING |
|
M341240 |
BOLT;SOCKET |
|
4393030 |
BOLT |
|
4427347 |
PLUG |
|
9134111 |
PLUG |
|
4509180 |
O-RING |
|
9134110 |
PLUG |
|
957366 |
O-RING |
|
495841 |
WASHER;SPRING |
|
A590912 |
WASHER;SPRING |
|
4436271 |
SENSOR;PRES. |
|
4365826 |
O-RING |
|
4265372 |
SENSOR;REVOL. |
|
4306888 |
O-RING |
|
A590106 |
WASHER;PLANE |
|
M340616 |
BOLT;SOCKET |
|
4252767 |
BRACKET |
|
M340613 |
BOLT;SOCKET |
|
4169516 |
WASHER;SPRING |
|
4515041 |
PIN;SPRING |
|
4348665 |
O-RING |
|
4180349 |
O-RING |
|
4343074 |
O-RING |
|
4320490 |
SEAL;OIL |
|
930451 |
RING;RETAINING |
|
4463047 |
KIT;SEAL |
|
