Pop12 Operator interface with LC-graphic display
Email:miya@mvme.cn
The Parker Pop panels are designed to be mounted on the front of some type of enclosure.
The PLC Port is used to communicate with the Compax or with another type of controller; if the panel is configured as an Pop HMI client, then this port may be used for the PopNet connection. Different electrical standards are available for the signals in the PLC port connector: RS-232, RS-422, RS-485 or Current Loop 20 mA. The cable used selects the appropriate signals. It is always necessary to use the correct cable type for on the Compax to be connected.
| Power supply voltage | DC 18 - 30 V |
| Power consumption (1) Back-up battery | 3 V 270mA Lithium, not rechargeable, life about 1 year, user replaceable, model: CR2430.Replace with same or equivalent battery with the working temperature of Pop. |
| Fuse | overcurrent protection device |
| Operating temperature 0 | 0 ÷ +50°C, |
| Storage temperature | -20 ÷ +70°C |
| Operating/storage humidity | 5 ÷ 95 % RH not-condensing |
| Vibrations | 10 ÷ 57 Hz, 0,075 mm peak 57 ÷ 150 Hz, 1 G |
| Shock | 50 g, 11 ms, 3 pulses per axis |
| Protection class | IP65 front panel |
| Keyboard reliability | > 3 million operations |
