EP DS3 Walkie Electric Stacker 1500kg, Narrow Aisle Compact Pallet Stacker with Built-in Charger
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
1-5 pieces 25-30 working days. 10 pieces bulk order 35-40 days
Brand:
EP
Product Description
Product Introduction
Most small & medium warehouses, e-commerce storage and factory workshops face 3 common troubles: narrow aisles inaccessible to large forklifts, mismatched stackers for multi-height racks, messy separate charging equipment occupying extra space.
EP DS3 walkie electric stacker is specially designed for light-duty vertical pallet handling. It supports 1500kg rated load capacity with a tiny turning radius of only 1455mm, matching narrow aisles over 2200mm. It fully covers pallet stacking, rack loading and finished goods transfer.
Why Choose Us
1. 6 Optional Mast Heights for All Rack Heights
2. Integrated Built-in Charger, Dual Battery Options
3. Auto Speed Reduction & Electromagnetic Brake for Safety
4. Compact Body Perfect for Narrow Aisles
5. Customizable Fork, Mast & Tiller Attachments
Product Specification
| Item | Specification |
| Model | DS3 |
| Rated Load Capacity | 1500kg |
| Service Weight | 520kg |
| Wheelbase / Turning Radius | 1210mm / 1455mm |
| Overall L×W×H (Mast Retracted) | 1727×834×2067mm |
| Min. Fork Lowered Height | 90mm |
Real Customer Application Cases
Configuration: DS3 standard 3018 mast, 80Ah AGM battery, 1150mm standard forks
Original Pain Points: Narrow warehouse aisles, low efficiency of manual stackers, separate external chargers
Actual Effect: Daily pallet handling capacity increased by 45%; built-in charger supports 24h shift work; annual maintenance cost reduced
FAQ
Q1: What is the maximum lifting height of DS3? Can customized higher mast be provided?
A: Standard max lift height 3018mm, optional max mast 3918mm with extended height 4432mm. Custom higher mast is unavailable currently.
A: Standard max lift height 3018mm, optional max mast 3918mm with extended height 4432mm. Custom higher mast is unavailable currently.
Q2: Does the built-in charger need extra charging cabinet?
A: No external charging cabinet required, directly connect to 220V industrial or household mains power.
A: No external charging cabinet required, directly connect to 220V industrial or household mains power.
Q3: How to choose between lead-acid and lithium battery version?
A: Select lithium ion for multi-shift non-stop operation with lighter weight & longer endurance; choose standard AGM lead-acid for single-shift low-budget use.
A: Select lithium ion for multi-shift non-stop operation with lighter weight & longer endurance; choose standard AGM lead-acid for single-shift low-budget use.
Q4: Can we customize charger voltage for overseas markets?
A: Multi-country voltage chargers are available for Europe, Southeast Asia and other regions.
A: Multi-country voltage chargers are available for Europe, Southeast Asia and other regions.
Q5: Can we replace forks separately if pallets have non-standard sizes?
A: 6 sizes of forks for optional separate replacement, no need to customize the whole stacker.
A: 6 sizes of forks for optional separate replacement, no need to customize the whole stacker.
