Portable Fiber Optic Cable Reel
Portable Tactical Fiber Optic Cable Tight Buffered Tube Cable
Product description of indoor tactical fiber optic cable
The Simplex cable uses single 900µm tight buffered fiber as fiber optic transmission medium, covered with aramid yarn as strength member,then extruded with thermoplastic polyurethane sheath.
The Polyurethane jacket with a excellent performance of anti-torsion and anti wear.It can be used and rolled up then used again elsewhere.Even with the rugged environments.
Tactical fiber optic cable tight buffered tube cable is used for outdoor video,traffic control etc telecommunication.
Also application for the military mobile.
Both end have LC, ST, FC, SC,PDLC and waterproof Connector or as requested.
| Item | Single mode | Multi mode | |
| Splicing Type | UPC | APC | PC |
| Insertion Loss | <or=0.3dB | <or=0.2dB | <or=0.3dB |
| Reture Loss | >or=45dB | >or=55dB | >or=35dB |
| Repeatability | <or=0.1dB | <or=0.1dB | <or=0.1dB |
| Temperature | -40/+80 | ||
Specifications&Performances
| Cable Count |
ITEM | CABLE OD.mm(a) |
S.S.T. OD.mm(b) |
T.B.O.F. OD.mm(C) |
| 4F | 4.5MM | Φ4.5±0.2 | Φ2.4±0.02 | Φ0.5 |
| 6F | 4.5MM | Φ4.5±0.2 | Φ2.6±0.03 | Φ0.5 |
| 8F | 5.0MM | Φ5.0±0.2 | Φ2.8±0.05 | Φ0.5 |
| 10F | 5.0MM | Φ5.0±0.25 | Φ3.0±0.05 | Φ0.5 |
| 12F | 5.5MM | Φ5.5±0.25 | Φ3.2±0.05 | Φ0.5 |
| 24F | 7.0MM | Φ7.0±0.3 | Φ4.3±0.05 | Φ0.5 |
♦Brief introduction of application
1. Military communication system.
2. Coal,oil,natural gas,geological exploration.
3. Broadcast television,temporary communication.
| Cable Count |
ITEM | CABLE OD. mm(a) |
CABLE WEIGHT (kg) |
MAXIMUM TENSILE | BEND RADIUS* | L.P. N/100mm |
||
| S.T. | L.T. | Dyn. | Sta. | |||||
| 4F | 4.5MM | Φ4.5±0.2 | 26.5 | 800 | 400 | 70 | 35 | 3000 |
| 6F | 4.5MM | Φ4.5±0.2 | 38.5 | 1000 | 500 | 100 | 50 | 3000 |
| 8F | 5.0MM | Φ5.0±0.2 | 33.0 | 1000 | 501 | 100 | 50 | 3000 |
| 10F | 5.0MM | Φ5.0±0.25 | 36.0 | 1000 | 502 | 120 | 60 | 3000 |
| 12F | 5.5MM | Φ5.5±0.25 | 39.0 | 1200 | 600 | 150 | 75 | 3000 |
| 24F | 7.0MM | Φ7.0±0.3 | 54.0 | 1500 | 750 | 170 | 85 | 3000 |
♦Note
1.Only a part of cables are listed in the table. Cables with other specifications can be inquired.
2.Cables can be supplied with a range of single mode or multimode fibers.
3.Specially designed Cable structure is available on request.
