SM / MM Square Bare Fiber Optical Cable Coupler Simplex / Duplex Channels
FTTH FC SC LC ST SM/MM RoHS Square Bare Fiber Optic Adapter
Square FC Bare fiber optical adapters are used as the medium to link the bare optical fiber to fiber optic equipment. It have the bare optical fiber inside on one side, the other side of the adapter is a connector that can plug into the equipment. It is used to quickly and easily terminate the fiber to the equipment.
| Type | Data | Unit |
| Adapter Type | SC/LC/FC/ST | |
| Insertion Loss | ≤0.2 | dB |
| Interchangeability | ≤0.2 | dB |
| Repeatability | ≤0.1 | dB |
| Temperature | -40~+85 | ℃ |
Feature:
1, With/Without flange Optional
2, Simplex , Duplex or Quad Optional
3, Zirconia Sleeve ,Compact design
4, Low insertional loss, High return loss
5, Comply with IEC, Telcordia GR 326 and JIS standard
6, LC/SC/FC/ST Type Optional
7, UPC or APC Optional
8, SM or MM Optional
The monthly production capacity is 10k, all products are designed and controlled under IEC standard, meet the requirement of Telcordia GR-326 and TIA/EIA as well.
