0.9 , 2.0 , 3.0mm Indoor Fiber Optic Patch Cord , Unarmored FO Cable
0.9,2.0,3.0mm Indoor Fiber Optic Cable Patch Cord Unarmored FO Cable
The cable contains 2 to 36 fibers which are individually buffered tight or semi-tight construction. Each fiber is individually protected in a mini cable. Aramid yarn will be applied either inside the mini cable or within the inner jacket of the cable. The color coded Mini. cable may be stranded around a central.
Typical Usages
3G, 4G base station
BBU, RRU, RRH, LTE
FTTA, FTTP, FTTX, WIMAX
Military, Mining and shipboard
Aerospace and Defense
Horizontal and Vertical Cabling
Typical Advantage
Waterproof and corrosion resistant
Field Installable
Armored Steel Tube for Rodent Resistance
With Big Capacity Data Transmission
Low Insertion Loss and High Return Loss
Technical Data
|
Item |
Single mode |
Multi mode |
|
|
Splicing Type |
UPC |
APC |
PC |
|
Insertion Loss |
<or=0.3dB |
<or=0.2dB |
<or=0.3dB |
|
Reture Loss |
>or=45dB |
>or=55dB |
>or=35dB |
|
Repeatability |
<or=0.1dB |
<or=0.1dB |
<or=0.1dB |
|
Temperature |
-40/+80 |
||
Specifications&Performances
|
Cable |
ITEM |
CABLE |
S.S.T. |
T.B.O.F. |
|
4F |
4.5MM |
Φ4.5±0.2 |
Φ2.4±0.02 |
Φ0.5 |
|
6F |
4.5MM |
Φ4.5±0.2 |
Φ2.6±0.03 |
Φ0.5 |
|
8F |
5.0MM |
Φ5.0±0.2 |
Φ2.8±0.05 |
Φ0.5 |
|
10F |
5.0MM |
Φ5.0±0.25 |
Φ3.0±0.05 |
Φ0.5 |
|
12F |
5.5MM |
Φ5.5±0.25 |
Φ3.2±0.05 |
Φ0.5 |
|
24F |
7.0MM |
Φ7.0±0.3 |
Φ4.3±0.05 |
Φ0.5 |
Fiber Parameters
|
No. |
Items |
Unit |
Specification |
|
|
G.652D |
||||
|
1 |
Mode Field Diameter |
1310nm |
μm |
9.2±0.4 |
|
1550nm |
μm |
10.4±0.5 |
||
|
2 |
Cladding Diameter |
μm |
124.8±0.7 |
|
|
3 |
Cladding Non-Circularity |
% |
≤0.7 |
|
|
4 |
Core-Cladding Concentricity Error |
μm |
≤0.5 |
|
|
5 |
Coating Diameter |
μm |
245±5 |
|
|
6 |
Coating Non-Circularity |
% |
≤6.0 |
|
|
7 |
Cladding-Coating Concentricity Error |
μm |
≤12.0 |
|
|
8 |
Cable Cutoff Wavelength |
nm |
λcc≤1260 |
|
|
9 |
Attenuation (max.) |
1310nm |
dB/km |
≤0.4 |
|
1550nm |
dB/km |
≤0.3 |
||
