QTZ125 (6515) Building Tower Crane 10t Load 50m Height Price

QTZ125 (6515) Building Tower Crane 10t Load 50m Height Price
Features
1) Working Radius (m): 65
2) Max. Load Capactiy (T): 10
3) Tip Load (T): 1.5
4) Mast Section dimension (m): 1.833×1.833×2.5 or 2*2*3m
5) Hoisting Mechanism Speed (m/min): 0-100 0-50
6) Motor power (kw): 45kw
7) Slewing Mechanism Speed (r/min): 0-0.6
8) Motor power (kw): 5.5×2
9) Trolleying Mechanism Speed (m/min): 0-60
10) Motor power (kw): 5.5

Specification


Advantage of QTZ125 External Climbing Tower Crane
a. Updated PLC can change the analog signal into digital signal, which shorten the faults removal time, improve its accuracy and anti-interrency capacity.
b. RCV turning control can be stepless speed regulated, which will results in precise brake and easy maintenance.
c. Soft lifting will produce no shock, which will improve the tower crane safety and its service life.
d. The most advanced and stable PLC controller is totally intelligently controlled, which will provide safe protection against the operator's mis-operation. It has faults detecting and signal testing functions.
e. There are fewer intermediate control components, which result in easy maintenance and higher reliability and safety.
f. All electrical components are from world famous brands.

Pictures
