D5030 12T 50m Boom Luffing Tower Crane 3m Mast 50m HUH Height
D5030 12T 50m Boom Luffing Tower Crane 3m Mast 50m HUH Height
Performance parameters of D5030: performance parameters and technical indexes reach both domestic and international advanced level.
• Max. jib length: 50m;
• Max. lifting capacity 12t;
• Max. hoisting capacity at jib tip:3.0t;
• Rated lifting moment: 1600 Kn.m;
• Max. freestanding height: 37.5m; Max. working height of anchored crane: 160m;
Specification
| Model | QTD160 (5030) Luffing Jib Tower Crane | |
| Working Radius (m) | 50 | |
| Max. Load Capacity (T) | 12 | |
| Tip Load (T) | 3.0 | |
| Free standing height (m) | 40 | |
| Max. Height with anchorages (m) | 162 | |
| Mast Section dimension (m) | 2×2×3, angle steel 200×20mm | |
| Hoisting Mechanism | Speed (m/min) | (a=2) 0-100; (a=4) 0-50 |
| Motor power (kw) | 45 | |
| Slewing Mechanism | Speed (r/min) | 0-0.6 |
| Motor power (kw) | 2*5.5 | |
| Trolleying Mechanism | Speed (m/min) | 0-10 |
| Motor power (kw) | 35 | |
| Jacking-up System | Speed (m/min) | 0.4 |
| Motor power (kw) | 11 | |
| Total Power (kw) | 91 | |
| Power Supply | 380V/50Hz or according to clients needs | |
Features
Quality manufacturing designed for reliable performance hour after hour
Easy maintenance access and built-in safety features to keep downtime to a minimum
Ergonomic cabs provide the comfort required for long hours on the job
The range provides fixed and mobile counterweight cranes for higher performance
Commercial Terms
Price: Negotiable
Delivery time: 15-30 days after receiving 30% advanced payment
Trade terms: FOB (qingdao)
Terms of Payment: T/T or L/C (30% advanced payment, 70% before shipment)
Packing: Standard Exporting Packing
Warranty: At least 12 months
Why choose us
1. A professional tower crane supplier in China with 15 years experience
2. Exported to more than 20 countries with ISO9001 & CE & GOST Certifications
3. Hydraulic self-climbing mechanism
4. Variable-frequency slewing mechanism
5. Varialbe-speed frequency PLC control System
6. Operation data display screen and Safety monitoring system (Black Box)
7. Various safety devices
Photos
