25 Pin Female D-SUB D Type Connector Dual Row 180° DIP Type For Connecting Computer
Price:
Negotiation
MOQ:
1000pcs
Delivery Time:
15-25 Working Days
Brand:
WCON
Product Description
D-SUB 25P Female D-SUB Connector Dual Row 180° DIP Type Brass With Back Fork
| Currenr Rating | 3.0AMP |
| Contact Resistance | 20mΩ Max |
| Withstand Voltage | 500V AC/DC |
| Insulation Resistance | 1000mΩ Min |
| Operation Temperature | ﹣55℃ to +105℃ |
| Contact Material | Brass |
| Contact Plating | Au Or Sn over Ni |
| Insulator Material | PBT+30%GF UL94V-0 |
| Shell | Cold Roller Steel,Ni Or Sn Plated |
| Nut | Brass,Sn Over Ni Plated |
Product Name: D-SUB connector
1. Features: the use of a wide range of environmental protection fireproof antioxidant electrical conductivity and long service life force is strong.
2. Material: PBT (green, black, white) plus fiber 30% UL94V-0 contact body material: brass (C3604)
3. Scope of application: used for connecting a computer, communication, medical equipment, wire and cable, aviation, digital, machinery and equipment, game consoles and other integrated circuit package pins and printed circuit board.
