Straight type 8P WCON PCB 2.54mm Round Pin Connector With PPS plastic black color ROHS
Price:
Negotiation
MOQ:
1000pcs
Delivery Time:
15-25Day
Brand:
WCON
Product Description
Straight type 8P WCON PCB 2.54mm Round Pin Connector With PPS plastic black color ROHS
|
1. Current Rating |
3.0AMP |
| 2. Contact Resistance | 10mΩ Max |
| 3. Dielectric Strength | Min 1000VRMS |
| 4. Mechanical Life | Min 500 cycles |
| 5. Operation Temperature | -40℃ to +105℃ |
| 6. Sleeve | Brass CuZn36Pb3(C36000) |
| 7. Contact Plating | Au over Ni |
| 8. Contact Pin |
∅0.46mm |
| 9. Insulator Material | PPS+30%GF(UL94V-0) |
| Product Name:2.54MM Machined pin connector | ||
| 1. features: the contact reliability, anti vibration, contact resistance | ||
| 2. product material: PPS, PA46 or PA6T insulator part plastic insulator part fire rating: UL94V-0 contact: brass parts | ||
| 3. scope of application: PCB computer communication cable, LED integrated circuit IC power car display automation in industry |
Drawing:Maching Pin 3510-301XXSXX119X1.pdf
2.54mm 1*8P 180°DIP WCON Connector Michined Pin Header H=3.0mm L=11.96mm.
| Our Certification | |||||||||
| The company also focused on creating their Dual-brand Strategy "WCON"and"WCONTEK", The "WCON" obtained a trademark registration in the world more than 50 countries and regions, and "WCONTEK" obtained the trademark registration in EU already. At present, "WCON" trademark have obtained "Guangdong Famous Brand" and "China Well-known Trademark" honor already. Dongguan Wcon that emphasize canonical enterprise management and high-quality requirements since its founding. We has already acquired ISO9001, TS16949 quality management system certification; ISO14001, QC080000 environment and management systems certification and OHSAS18001 occupation health safety management system certification. The company main 13 series products obtained American UL & CUL certification, with the No. E248993, E46999. All items are in line with EU RoHS and REACH environmental green requirements. |
