8 P PA66 Electrical Pcb Terminal Block Connector Open Type 5.08mm
5.08mm 8P PA66 Terminal Blocks Connector SN Plated Male Pluggable Open type
| Current Rating | 18A |
| Voltage Rating | 300v |
| Contact Resistance | 8milliohm Max |
| Withstand Voltage | AC2000V |
| Insulation Resistance | 1000Megohm Min |
| Operation Temperature | ﹣40℃ to +105℃ |
| Housing Material | PA66+30%GF(UL94V-0) |
| Contact Material | Brass |
| Inlay Material | Brass |
Product Name: terminal
1. Product features: switching high frequency high voltage insulation life long seismic
2. Product material: copper alloy, or copper alloy, electroplating nickel, or nickel alloy
3. Application: mainly used in communications, lighting, security and etc.. And the application of industry pluggable terminal is the main pan, such as frequency conversion, riot, numerical control panel, access controller, sensor, PLC, instrumentation, power, servo drive, the common requirements of these applications for pluggable terminal industry are: insertion force should be smooth, contact resistance to be small, must be able to meet the certain life and fatigue, so higher requirements for the metal shrapnel material. This requires that product designers have certain experience in structure and material. For the fence type terminal applications: power supply, relay (especially double terminal), frequency converter, the elevator industry (less), air conditioning.
