Single Row 2.54 mm Straight Round Pin Header H=3.0 Black ROHS

Price Negotiable
Price: Negotiation
MOQ: 1000pcs
Delivery Time: 15-25Day
Brand: WCON
Product Description

Single Row 2.54 Mm Pin Header Straight Round Pin Header Current Rating 3.0AMP



1. Current Rating 3.0AMP
2. Contact Resistance 10mΩ Max
3. Dielectric Strength Min 1000VRMS
4. Mechanical Life Min 500 cycles
5. Operation Temperature -40℃ to +105℃
6. Sleeve Brass CuZn36Pb3(C36000)
7. Contact Plating Au over Ni
8. Contact Pin ∅0.46mm
9. Insulator Material PPS+30%GF(UL94V-0)



Product Name: 1.27mm Michined pin connector

1. Straight Pin Header features: the contact reliability, anti vibration, contact resistance

2. Straight Pin Header material: PPS, PA46 or PA6T insulator part plastic insulator part fire rating: UL94V-0 contact: brass parts

3. scope of Straight Pin Header application: PCB computer communication cable, LED integrated circuit IC power car display.






 1.27mm Pcb Female Header / 20 Pin Header Connector 180°DIP PPS 30％GF UL94V-0Drawing:Machined Pin header 3510-301XXSXX119X1.pdf
